3˝
3˝
34 ½˝
24 / ˝
Sink
PBBC
PB
Illustration is Right Hand hinging
Kitchen Side
Kitchen Side
Peninsula Side
Peninsula Side
Blind panel
w/3” filler
24 / ˝
3” Filler
w/toekick
backer
E19
Base Corner Cabinets
Base Cabinets
Base Blind Corner
Specify R or L
BBC39 R or L
BBC42 R or L
BBC45 R or L
BBC48 R or L
BBC51 R or L
• R or L indicates blind
• One drawer
• Blind Panel with 3” filler included, shipped
unattached
I
Roll-out Trays (ROT) cannot be included
when a Reduced Depth (RD) option of less
than 18” is selected
•
Note
: When depth is reduced to 12” or
15”, drawers become a false front
l
PE
l
APC
l
RD12
l
RD15
l
RD18
l
RD21
I
1ROT
2ROT
1FWROT
2FWROT
2DROT
2DFWROT
l
CFO
34 ½˝
24˝
Blind Right shown
Peninsula Base Blind Corner Single Door
Specify R or L
PBBC27 R or L
• One adjustable shelf
• Cabinet is 24” wide
• Cabinet can be pulled a maximum of 3”
from wall
• Working drawer and door(s) on peninsula
side
• Use to start a peninsula run
• One 3” filler (BF3) and toespace assembly
(toekick backer) included, shipped
unattached
• Blind Panel with 3” filler included, shipped
unattached
• Front and back face frames are pre-drilled for
optional roll out trays
l
PE
l
APC
RD12
RD15
RD18
RD21
l
1ROT
l
2ROT
1FWROT
2FWROT
l
2DROT
2DFWROT
CFO
