E33
Base Accessories
Base Cabinets
Base End Panel w/Stile
BEP3
BEP6
• For right or left hand use
• The mounting cleat is finished but is
not
a
matching wood species to the face
• Toespace notch
must
be field cut
• Available with Plywood Ends (PE)
• Available in All Plywood Construction (APC)
v
C
v
M
v
O
24˝
34 ½˝
3˝, 6˝
Field cut
Toespace
Stile
Matching Base End Panel
MBEP2434
• Provides a finished furniture look to
34 1/2” base cabinets
• Includes end panel with decorative door
• For right or left hand use
• 5/32” thick veneered plywood panel
• Full overlay door styles shipped unattached to
panel. When installed, door overlaps cabinet
frame edge to provide matching reveals
• Partial overlay door styles; door shipped
attached to panel
• Field installation only
• Toespace notch
must
be field cut
v
C
v
M
v
O
Field cut
Toespace
/ ˝
34 ½˝
23 ¼˝
Item
MBEP2434
23 ¼˝
Width
34 ½˝
Height
29 ¼˝
Height
23 / ˝
Width
28˝
Height
22 ¼˝
Width
Panel
Size
Full
Overlay
Partial
Overlay
