D9
Wall Corner Cabinets
Wall Cabinets
Wall Blind Corner Single Door 23 1/2” H and 30” H
Specify R or L
One shelf
23 1/2” High
WBC3024 R or L
WBC3924 R or L
Specify R or L
Two shelves
30” High
WBC2730 R or L
WBC3030 R or L
WBC3330 R or L
WBC3630 R or L
WBC3930 R or L
• R or L indicates blind
• Adjustable shelves
• Door hinged to frame center stile
• Any wall cabinet over 24˝ wide or 30˝ high
or higher with a depth greater than 12˝
and/or with butt doors must be installed
between two (2) cabinets, a cabinet and a
wall or supported from below
• Do
not
pull cabinet more than 2 7/8” from
corner
• Blind Panel with 3” filler included, shipped
unattached
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
BIS
MD
SV
MI
l
CFO
23 ½˝
30˝
12˝
Wall Blind Corner Double Door 30” H
Specify R or L
WBC4530 R or L
WBC5130 R or L
• R or L indicates blind
• Two adjustable shelves
• Two different width doors; the narrower is
located next to the blind panel
• Any wall cabinet over 24˝ wide or 30˝ high
or higher with a depth greater than 12˝
and/or with butt doors must be installed
between two (2) cabinets, a cabinet and a
wall or supported from below
• Do
not
pull cabinet more than 2 7/8” from
corner
• Blind Panel with 3” filler included, shipped
unattached
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
BIS
MD
SV
MI
l
CFO
30˝
12˝
Wall Blind Corner Single Door 36” H
Specify R or L
WBC2736 R or L
WBC3036 R or L
WBC3336 R or L
WBC3936 R or L
• R or L indicates blind
• Three adjustable shelves
• Door hinged to frame center stile
• Any wall cabinet over 24˝ wide or 30˝ high
or higher with a depth greater than 12˝
and/or with butt doors must be installed
between two (2) cabinets, a cabinet and a
wall or supported from below
• Do
not
pull cabinet more than 2 7/8” from
corner
• Blind Panel with 3” filler included, shipped
unattached
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
BIS
MD
SV
MI
l
CFO
36˝
12˝
Wall Blind Corner Single Door 39” and 42” H
Specify R or L
39” High
WBC2739 R or L
WBC3039 R or L
WBC3339 R or L
WBC3939 R or L
Specify R or L
42” High
WBC2742 R or L
WBC3042 R or L
WBC3342 R or L
WBC3942 R or L
• R or L indicates blind
• Three adjustable shelves
• Door hinged to frame center stile
• Any wall cabinet over 24˝ wide or 30˝ high
or higher with a depth greater than 12˝
and/or with butt doors must be installed
between two (2) cabinets, a cabinet and a
wall or supported from below
• Do
not
pull cabinet more than 2 7/8” from
corner
• Blind Panel with 3” filler included, shipped
unattached
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
BIS
MD
SV
MI
l
CFO
39˝
42˝
12˝
