C13
Construction Options
Specifications and Options
4 Deep Roll-out Trays
4DROT
• Sides, front and back, are 1/2” solid hardwood with
3-ply 5.2mm thick plywood bottom panel
• 1 15/16” deep scalloped finger pull cut out
• Available for most 2 door Base and Universal
cabinets with center stile
• Natural finish
• 3/4 extension side mount glide
• 75 lb. capacity
• Shelves are omitted from cabinets when Roll-Out
Tray (ROT) options are selected
•
Note
: Only available in 24” deep cabinets
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
l
4DROT
6DROT
2DFWROT
MI
CFO
6 Deep Roll-out Trays
6DROT
• Sides, front and back, are 1/2” solid hardwood with
3-ply 5.2mm thick plywood bottom panel
• 1 15/16” deep scalloped finger pull cut out
• Available for most 3 door Base and Universal
cabinets
• Natural finish
• 3/4 extension side mount glide
• 75 lb. capacity
• Shelves are omitted from cabinets when Roll-Out
Tray (ROT) options are selected
•
Note
: Only available in 24” deep cabinets
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
l
6DROT
2DFWROT
MI
CFO
2 Deep Full-Width Roll-out Trays
2DFWROT
• Full-width deep tray spans the full width of cabinet
• Sides, front and back, are 1/2” solid hardwood with
3-ply 5.2mm thick plywood bottom panel
• 1 15/16” deep scalloped finger pull cut out
• Available for most Butt door (cabinets with a B
suffix) Base and Universal cabinets
• Natural finish
• 3/4 extension side mount glide
• 75 lb. capacity
• Shelves are omitted from cabinets when Roll-Out
Tray (ROT) options are selected
•
Note
: Only available in 24” deep cabinets
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
l
2DFWROT
MI
CFO
