KraftMaidONE Spec - page 25

C5 Cabinet Specifications
Specifications and Options
34 1/2” Vanity Frame Dimensions
• Vertical opening sizes are preceded by an asterisk (*)
• Unless otherwise noted, all stiles and rails are 1 1/2” wide
• 3” wide vertical stiles divide double door cabinets, +
indicates stiles are removed on butt door cabinets
*8"
*5"
*20 ½˝ *20 ½˝ *20 ½˝ *20 ½˝ *5" 3"
*5"
*45"
*20 ½˝
*5"
30"
4 ½˝
*5" *5"
*5"
*5"
1 ½˝ Countertop
*5" *5"
3" 3" 3"
4 ½˝ 4 ½˝ *5" *5"
*8"
30" 48"
VWB2430BUTT VLC1848
VCD•3 VSB•2 VSB•2 VSB VD•4
+ 34 ½˝
1 1 ⁄
4"
1 1 ⁄
4"
Vanity Tall Dimensions
• Vertical opening sizes are preceded by an asterisk (*)
• Unless otherwise noted, all stiles and rails are 1 1/2” wide
2"
*27"
*59 1⁄
2"
96"
21/2"
*20 1/2"
*59 1⁄2"
90"
2"
*15"
*59 1⁄2"
84"
Vanity Linen Cabinet Heights
4 1⁄
2"
79 1 ⁄
2"
85 1 ⁄
2"
91 1 ⁄
2"
VLC151884 VLC151896 VLC151890
