24”wide Butt
door options
With Glass
Prepared for Glass
C10
Construction Options
Specifications and Options
Bistro Glass
With Glass
18” - 30” H
1BIS1
2BIS1
4BIS1
Prepared for Glass
18” - 30” H
1DRS.PREP1
2DRS.PREP1
4DRS.PREP1
With Glass
36” - 42” H
1BIS2
2BIS2
Prepared for Glass
36” - 42” H
1DRS.PREP2
2DRS.PREP2
• 1/8” removable tempered
glass with BIS option. No
glass with DRS.PREP option
• Available for select wall
cabinets
• Example: W1830R-1BIS1 (1
Qty, Code, Size), W3636-
2BIS2 (2 Qty, Code, Size)
•
Note
: Available for the
following door styles:
Bellwether, Chesterhill,
Flaxton, Fox Pointe,
Glenmoor, Rexton and
Talmadge
•
Note
: Mitered door styles
cannot be field modified for glass
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
l
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
With Glass
Prepared for Glass
Gray color coding indicates new product, size or code.
Savannah Mullion Glass
With Glass
18” - 30” H
1SV1
2SV1
4SV1
Prepared for Glass
18” - 30” H
1SV.PREP1
2SV.PREP1
4SV.PREP1
With Glass
36” - 42” H
1SV2
2SV2
Prepared for Glass
36” - 42” H
1SV.PREP2
2SV.PREP2
• 1/8” removable tempered
glass with SV option. No
glass with SV.PREP option
• Available for select wall
cabinets
• All doors have two vertical
and two horizontal mullions,
except Talmadge 24” wide
Butt door cabinets, which
have only one vertical
mullion
• Example: W1830R-1SV1 (1
Qty, Code, Size), W3636-2SV2
(2 Qty, Code, Size)
•
Note
: Available for the
following door styles: Ambridge and Talmadge
•
Note
: Mitered door styles cannot be field
modified for glass
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
l
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
Gray color coding indicates new product, size or code.
Traditional Mullion Glass
With Glass
18” - 30”H
1MD1
2MD1
4MD1
Prepared for Glass
18” - 30”H
1MD.PREP1
2MD.PREP1
4MD.PREP1
With Glass
36” - 42” H
1MD2
2MD2
Prepared for Glass
36” - 42” H
1MD.PREP2
2MD.PREP2
• 1/8” removable tempered
glass with MD option. No
glass with MD.PREP option
• Mullions are equally divided
• Available for select wall
cabinets
• For 15” and 18” wide
cabinets: 36” and 42” high
cabinets have 2x4 lites, 30”
high cabinets have 2x3 lites
and 18” and 24” high cabinets
have 2x2 lites
• For 21” and 24” wide
cabinets: 36” and 42” high
cabinets have 3x4 lites, 30”
high cabinets have 3x3 lites and 24” high
cabinets have 3x2 lites
• Example: W1830R-1MD1 (1 Qty, Code, Size),
W3636-2MD2 (2 Qty, Code, Size)
•
Note
: Available for the following door styles:
Fox Pointe, Glenmoor and Rexton
•
Note
: Mitered door styles cannot be field
modified for glass
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
l
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
With Glass
Prepared for Glass
Gray color coding indicates new product, size or code.
