D17
Wall Microwave Cabinets
Caution
: Additional support is required.
Wall Cabinets
Wall Microwave Shelf Cabinet
30” High
WMSC271230 (Butt)
36” High
WMSC241236 (Butt)
WMSC271236 (Butt)
42” High
WMSC271242 (Butt)
• 3/4” thick shelf extends 6 25/32” beyond
face frame
• Matching laminate interior
• No shelf in upper section
• Shelf shipped unattached for easier
installation; mounting hardware included
• Designed for countertop style microwaves
•
Note
: Must be installed between two cabinets
or between cabinet and side wall
l
PE
l
APC
ID21
ID24
l
CFO
Opening Sizes
Cabinet
WMSC241236
WMSC271230
WMSC271236
18¾˝ high x 21˝ wide x 18˝ deep (shelf)
15¾˝ high x 24˝ wide x 18˝ deep (shelf)
18¾˝ high x 24˝ wide x 18˝ deep (shelf)
21¾˝ high x 24˝ wide x 18˝ deep (shelf)
WMSC271242
12˝
18˝
30˝
36˝
42˝
12˝
15˝
18˝
Wall Microwave Shelf
12” Deep
WMS271218
WMS301218
15” Deep
WMS271518
WMS301518
• 3/4” thick shelf extends 3 25/32” beyond
face frame of cabinet
• Grain direction runs lengthwise (when
applicable)
• Shelf shipped unattached for easier
installation; mounting hardware included
• Designed for countertop style microwaves
•
Note
: Must be installed between two cabinets
or between cabinet and side wall
l
PE
l
APC
ID21
ID24
CFO
Opening Sizes
Cabinet
WMS271218
WMS301218
WMS271518
24˝ wide x14 ¼˝ high x 15˝ deep
27˝ wide x14 ¼˝ high x 15˝ deep
24˝ wide x14 ¼˝ high x 18˝ deep
27˝ wide x14 ¼˝ high x 18˝ deep
WMS301518
12˝, 15˝
18˝
