Wall Corner Cabinets
Wall Cabinets
Peninsula Wall Blind Corner 30” H
Specify R or L
PWBC2730 R or L
• R or L indicates blind
• Two adjustable shelves
• Door hinged to frame center stile
• Single door on kitchen side; double doors
on peninsula side
• Do
not
pull cabinet more than 2 7/8” from
corner
• Blind Panel with 3” filler included, shipped
unattached
Peninsula Wall Cabinets must be
installed against a soffit, ceiling or
supported by a countertop. See
Cabinet installation guide for specific
instructions
l
PE
l
APC
RD9
ID15
ID18
ID21
ID24
BIS
MD
SV
MI
CFO
12 / ˝
30˝
(excluding doors)
Wall Angle 12” Deep
Specify R or L
Two shelves
WA2430 R or L
Three shelves
WA2436 R or L
WA2439 R or L
WA2442 R or L
• Adjustable shelves
• Back corner removed for easy installation
• Full and Partial Overlay door widths are
similar to avoid interference with adjacent
cabinet doors
• Adjacent cabinets can be installed directly
without fillers
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
Do
not
design a corner cabinet
adjacent to an object deeper than
the end panel. The door of the
corner cabinet may
not
function properly.
l
PE
l
APC
RD9
ID15
ID18
ID21
ID24
I
BIS
I
MD
I
SV
I
MI
l
CFO
30˝
36˝
39˝
42˝
17"
24"
24"
12"
12"
Wall Angle 15” Deep
Specify R or L
Two shelves
WA2730 R or L
Three shelves
WA2736 R or L
WA2739 R or L
WA2742 R or L
• Adjustable shelves
• Back corner removed for easy installation
• Full and Partial Overlay door widths are
similar to avoid interference with adjacent
cabinet doors
• Adjacent cabinets can be installed directly
without fillers
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
l
PE
l
APC
RD9
ID15
ID18
ID21
ID24
I
BIS
I
MD
I
SV
I
MI
l
CFO
30˝
36˝
39˝
42˝
17"
27"
27"
15"
15"
