Tall Appliance Cabinets
Note
: Remember to remove the white plastic “feet” from the bottom of all tall cabinets before
installation. Their sole purpose is to protect the floor after the cabinets are unboxed. Leaving them on
will result in uneven installation.
Tall Cabinets
Microwave Cooking Center–Extended Opening
Opening Trimmable to: 22” x 21 1/2”
MCCE272484 (Butt)
MCCE272487 (Butt)
MCCE272490 (Butt)
MCCE272493 (Butt)
MCCE272496 (Butt)
Opening Trimmable to: 25” x 21 1/2”
MCCE302484 BUTT
MCCE302487 BUTT
MCCE302490 BUTT
MCCE302493 BUTT
MCCE302496 BUTT
• One adjustable shelf in lower section
• One standard drawer and one cutting center
• Includes adjustable shelves in upper section:
84” & 87” high—one shelf; 90” & 93” high—
two shelves; 96” high—three shelves
• Pull-out cutting board installed
• Top drawer will be slab, including DRPD,
on all full-overlay door styles except
Somersworth and Thornton which will be
five-piece
I
Wide Bottom Rail (WR) and Recessed Toe
Kick (RTK)
not
available on 93” & 96” high cabinets
• Toe kick is shipped separately on 93˝ & 96˝ high cabinets
I
Void Toe Kick (VTK) is
not
available on 93” and 96” high
cabinets
I
Glass doors available for top doors only
Remember to order a 3/16” skin (WSK) for the
exposed ends of 93” & 96” high cabinets to
conceal the seam between the loose toe kick
and the cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
RD
ID
IF
I
WR
l
XS
I
GD
I
RTK
I
VTK
24˝
84˝
87˝
90˝
93˝
96˝
21˝
23 ½˝
27˝
30˝
33˝
1/2” Overlay
Full Overlay
Cut out dimensions
Yoke sizes
Cut out dimensions
Yoke sizes
Cabinet
Min.
Width
Max.
Width
Min.
Height
Max.
Height
Yoke
Width
Yoke
Height
Min.
Width
Max.
Width
Min.
Height
Max.
Height
Yoke
Width
Yoke
Height
MCCE272484
18”
22”
15 1/16”
17"
25"
24"
19 5/8" 23 5/8" 15 1/16"
17"
26 5/8"
24"
MCCE272487
18”
22”
14 9/16" 16 1/2"
25"
23 1/2" 19 5/8" 23 5/8" 15 9/16" 17 1/2" 26 5/8" 24 1/2"
MCCE272490/93
18”
22”
14 9/16" 16 1/2"
25"
23 1/2" 19 5/8" 23 5/8" 15 1/16"
17"
26 5/8"
24"
MCCE272496
18”
22”
14 9/16" 16 1/2"
25"
23 1/2" 19 5/8" 23 5/8" 14 11/16" 16 5/8" 26 5/8" 23 5/8"
MCCE302484
21”
25”
15 1/16” 16 1/2"
28"
24"
22 5/8" 26 5/8" 15 1/16"
17"
29 5/8"
24"
MCCE302487
21”
25”
14 9/16"
17"
28"
23 1/2" 22 5/8" 26 5/8" 15 9/16" 17 1/2" 29 5/8" 24 1/2"
MCCE302490/93
21”
25”
14 9/16" 16 1/2"
28"
23 1/2" 22 5/8" 26 5/8" 15 1/16"
17"
29 5/8"
24"
MCCE302496
21”
25”
14 9/16" 16 1/2"
28"
23 1/2" 22 5/8" 26 5/8" 14 11/16" 16 5/8" 29 5/8" 23 5/8"
Microwave Cooking Center w/Drawer Storage–Extended Opening
Opening Trimmable to: 22” x 19 1/2”
MCCDE272484 (Butt)
MCCDE272487 (Butt)
MCCDE272490 (Butt)
MCCDE272493 (Butt)
MCCDE272496 (Butt)
Opening Trimmable to: 25” x 19 1/2”
MCCDE302484 BUTT
MCCDE302487 BUTT
MCCDE302490 BUTT
MCCDE302493 BUTT
MCCDE302496 BUTT
• Two 7” deep drawers, one 2 1/4” drawer with
Roll-out Shelf Kit (ROSTK) above
• Includes adjustable shelves in upper section:
84” & 87” high—one shelf; 90” & 93” high—
two shelves; 96” high—three shelves
I
Wide Bottom Rail (WR) and Recessed Toe
Kick (RTK)
not
available on 93” & 96” high
cabinets
• Toe kick is shipped separately on 93˝ & 96˝
high cabinets
I
Void Toe Kick (VTK) is
not
available on 93”
and 96” high cabinets
l
PE
l
APC
l
APFC
l
FPEB
l
MI
RD
ID
IF
I
WR
l
XS
l
GD
I
RTK
I
VTK
84˝
87˝
90˝
93˝
96˝
21˝
23 ½˝
27˝
30˝
33˝
24˝
Cut out dimensions
Yoke sizes
Cut out dimensions
Yoke sizes
Cabinet
1/2” Overlay
Full Overlay
Min.
Width
Max.
Width
Min.
Height
MCCDE272484
MCCDE272487/90/93/96
MCCDE302484
MCCDE302487/90/93/96
14˝
14˝
17˝
17˝
22˝
22˝
25˝
25˝
11˝
10
1
˝
11˝
10
1
˝
Max.
Height
17
2
˝
16
3
˝
17
2
˝
16
3
˝
20
2
˝
19
3
˝
20
2
˝
19
3
˝
Yoke
Width
Yoke
Height
25˝
25˝
28˝
28˝
Min.
Width
Max.
Width
Min.
Height
15
6
˝
15
6
˝
18
6
˝
18
6
˝
23
6
˝
23
6
˝
26
6
˝
26
6
˝
12
4
˝
12
4
˝
12
4
˝
12
4
˝
Max.
Height
19
5
˝
18
7
˝
19
5
˝
18
7
˝
21
6
˝
21
6
˝
21
6
˝
21
6
˝
Yoke
Width
Yoke
Height
26
6
˝
26
6
˝
29
6
˝
29
6
˝
