312 / 601
F23
Tall Cabinet Accessories
Tall Cabinets
Tall Cabinet
Accessories
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
PE
Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI
Matching Interior
RD Reduced Depth
ID Increased Depth
WR Wide Bottom Rail
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
RTFC 3 15 84
code
width depth height
Oven Trim Kit
For OC_D
Width x Height
OTK24 D
23 5/8” x 53 1/8”
OTK27 D
26 5/8” x 53 1/8”
OTK30 D
29 5/8” x 53 1/8”
OTK31 D
30 1/8 x 53 1/8”
OTK33 D
32 5/8” x 53 1/8”
For OC_DE & OC_U Width x Height
OTK24 DE
23 5/8” x 60 5/8”
OTK27 DE
26 5/8” x 60 5/8”
OTK30 DE
29 5/8” x 60 5/8”
OTK31 DE
30 1/8” x 60 5/8”
OTK33 DE
32 5/8” x 60 5/8”
For OC_S & OC_.2D Width x Height
OTK24 S
23 5/8” x 32 5/8”
OTK27 S
26 5/8” x 32 5/8”
OTK30 S
29 5/8” x 32 5/8”
OTK31 S
30 1/8 x 32 5/8”
OTK33 S
32 5/8” x 32 5/8”
OTK39 S
38 5/8˝ x 32 5/8˝
For OC_DD
Width x Height
OTK24 DD
23 5/8” x 50 1/8”
OTK27 DD
26 5/8” x 50 1/8”
OTK30 DD
29 5/8” x 50 1/8”
OTK31 DD
31 1/8” x 50 1/8”
OTK33 DD
32 5/8” x 50 1/8”
• 5/8” wood veneer construction except for
Woodgrain Laminate door styles, which will
have 3/4” wood veneer construction
• Oven Trim Kits (OTK) will be supplied in
plain-sawn material for Quartersawn door
styles
• Painted hardwood supplied for EverCore™
• Woodgrain Laminate door styles default to vertical
design slab
• Front and back sides are finished
• Edgebanded all four sides
• 3/4” Thick for Wood Grain Laminates
• 3/4” Quartersawn panel supplied for Crafted Doors
PE
APC
APFC
FPEB
MI
RD
ID
WR
Grey color coding indicates new product, size or code.
Grey color coding indicates new product, size or code.
Double Oven Opening Kit
DOK24
DOK27
DOK30
DOK31
DOK33
• Includes 1/2” Viraguard clad shelf with 3/4”
Pine mounting supports and 3” wide 3/4”
solid wood center rail to match cabinet
exterior
• For installing two appliances in one oven
cabinet
• Painted hardwood supplied for EverCore™
PE
l
APC
APFC
FPEB
MI
RD
ID
WR
