307 / 601
Top
Center
Bottom
Cabinet
Width
Min.
Width
Max.
Width
Min.
Height
Max.
Height
Min.
Height
Max.
Height
Min.
Height
Max.
Height
27"
21"
25"
15”
24 1/2” 21 1/2” 27 1/2”
9”
13 1/2”
30"
24"
28"
15”
24 1/2” 21 1/2” 27 1/2”
9”
13 1/2”
31 1/2” 25 1/2" 29 1/2"
15”
24 1/2” 21 1/2” 27 1/2”
9”
13 1/2”
33"
27"
31"
15”
24 1/2” 21 1/2” 27 1/2”
9”
13 1/2”
Cut out dimensions
F18
Tall Appliance Cabinets
Note
: Remember to remove the white plastic “feet” from the bottom of all tall cabinets before
installation. Their sole purpose is to protect the floor after the cabinets are unboxed. Leaving them on
will result in uneven installation.
Tall Cabinets
Oven Cabinet–Combination w/3” Stiles
84” High
OC272484 (Butt)C
OC302484 (Butt)C
OC312484 (Butt)C
OC332484 BUTTC
87” High
OC272487 (Butt)C
OC302487 (Butt)C
OC312487 (Butt)C
OC332487 BUTTC
90” High
OC272490 (Butt)C
OC302490 (Butt)C
OC312490 (Butt)C
OC332490 BUTTC
93” High
OC272493 (Butt)C
OC302493 (Butt)C
OC312493 (Butt)C
OC332493 BUTTC
96” High
OC272496 (Butt)C
OC302496 (Butt)C
OC312496 (Butt)C
OC332496 BUTTC
• Includes adjustable shelves in upper section: 84˝, 87”
& 90˝ high—no shelves; 93˝ & 96˝ high—
one shelf
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Center 10” rail can be removed for double
oven application
I
Wide Bottom Rail (WR) and Recessed
Toe Kick (RTK)
not
available on 93” & 96”
high cabinets
• Toe kick is shipped separately on 93˝ &
96˝ high cabinets
I
Void Toe Kick (VTK) is
not
available on
93” and 96” high cabinets
•
Not
available with knife hinge door option
• Roll-out Trays (ROT) are
not
available for 31 1/2” wide
cabinets
I
Maximum Increased Depth (ID) is 27”
•
Note
: When ordering glass doors in full overlay door
styles, a portion of the 3” face frame will be visible
Best used for appliance combinations such
as; microwave, single oven, and warming
drawer or double oven and warming drawer
Remember to order a 3/16” skin (WSK) for
the exposed ends of 93” & 96” high cabinets
to conceal the seam between the loose toe
kick and the cabinet.
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
I
ID
IF
I
WR
l
XS
l
GD
I
RTK
I
VTK
24˝
84˝
87˝
90˝
93˝
96˝
12˝
15˝
18˝
21˝
23 ½˝
Grey color coding indicates new product, size or code.
Oven Cabinet–Universal
84” High
u
OC272484 (Butt)U
s
OC302484 BUTTU
s
OC332484 BUTTU
87” High
u
OC272487 (Butt)U
s
OC302487 BUTTU
s
OC332487 BUTTU
90” High
u
OC272490 (Butt)U
s
OC302490 BUTTU
s
OC332490 BUTTU
93” High
u
OC272493 (Butt)U
s
OC302493 BUTTU
s
OC332493 BUTTU
96” High
u
OC272496 (Butt)U
s
OC302496 BUTTU
s
OC332496 BUTTU
• Includes adjustable shelves in upper
section: 84” & 87” high—no shelves; 90”
& 93” high—one shelf; 96” high—two
shelves
• Adjustable floor
• Three standard height drawers
• Drawers are removable to accommodate
increased oven height
• Oven Trim Kit (overlay panel) available
for a full overlay look; see Tall Accessories
section of this book
I
Wide Bottom Rail (WR) and Recessed Toe Kick
(RTK)
not
available on 93” & 96” high cabinets
• Toe kick is shipped separately on 93˝ & 96˝ high
cabinets
I
Void Toe Kick (VTK) is
not
available on 93” and 96”
high cabinets
• One deep drawer
• Oven cutout requirements
must
be 1 1/2” less than
maximum allowable cutout in order to use Oven
Trim Kit (OTK)
I
Maximum Increased Depth (ID) is 27”
Most major appliance manufacturers will
tell you that their 27” wide ovens will fit
into a 27” oven cabinet and their 30” wide
ovens will fit into a 30” cabinet. In most cases this is
true. However, the look this creates may
not
be
appealing because the stiles will be concealed by the
appliance. To solve this problem, you can order a
30” oven cabinet for a 27” oven and a 33” oven
cabinet for a 30” oven, etc.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
I
ID
IF
I
WR
l
XS
l
GD
I
RTK
I
VTK
24˝
84˝
87˝
90˝
93˝
96˝
18˝
21˝
23 ½˝
27˝
30˝
23
50
44 ¼˝
60˝
30˝
38˝
cutout
dimensions
½˝
½˝
Cut out dimensions
Cabinet
Width
1/2”
Overlay
Full
Overlay
Min.
Width
Max.
Width
Min.
Height
Max.
Height
Max.
Height
27˝
30˝
33˝
21˝
21˝
24˝
25˝
28˝
31˝
23
2
˝
23
2
˝
23
2
˝
31˝
31˝
31˝
30˝
30˝
30˝
u
3˝ stiles
s
4 1/2” stiles routed to 1 1/2” in the door area
