Base Cabinets
Base Cabinets
Apron Sink Base Extended 27” Deep
APSBE3027 BUTT
APSBE3327 BUTT
APSBE3627 BUTT
APSBE3927 BUTT
APSBE4227 BUTT
• No shelf
• 3” top stiles
• Maximum cutout height is 11 3/4˝
• Additional support rails
are required–refer to sink
manufacturer
• All Plywood Furniture
Construction (APFC) will be
supplied when All Plywood
Construction (APC) is selected;
cabinets will have standard
furniture plywood ends
• Includes a Touch-Up Kit (TUK)
• Roll-out Trays (ROT) are
not
available
•
Note:
Be sure to follow manufacturer’s specifications to
ensure proper sink fit
We recommend using a Filler Extension (FE)
on 27” deep cabinets if adjacent cabinetry
will
not
be pulled flush to the Sink Base
Cabinetry
l
PE
l
APC
APFC
v
FPEB
l
MI
DE
OE
l
RD
IF
TWR
l
WR
l
XS
XSG
l
GD
RTK
RTKP
l
VTK
27˝
34
8˝
29˝
5
11¾˝
max
cutout
½˝
½˝
3˝
3˝
New
Grey color coding indicates new product, size or code.
Sink Base Blind Corner
Specify R or L
SBBC51 R or L
SBBC54 R or L
SBBC57 R or L
SBBC60 R or L
SBBC63 R or L
• Blind panel (stile) is 8” wide
• Blind opening is covered with an
unfinished panel
• R or L indicates blind
• Right blind shown
• Door is hinged from blind panel
• Filler included
• Overlay Panel for Base Blind Corner (OPWBC)
must
be ordered separately
• False drawer front
• Factory installed Roll-out Trays (ROT) are
not
available
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
l
RD
IF
TWR
l
WR
l
XS
XSG
l
GD
l
RTK
l
RTKP
l
VTK
24˝
24˝
SBBC51
SBBC54-63
34 ½˝
34 ½˝
Wall Space “A”
Exposed
Front “B”
Door
Open
“C”
Wall Space “A”
Exposed
Front “B”
Door
Open
“C”
Min
★
Max.
Min
★
Max
Cab.
Width Min
★
Max Min
★
Max
Cab.
Width
SBBC51
49 ½˝ 52 ¾˝ 25 ½˝ 28 ¾˝
21"
48"
50 ¼˝ 53 ¾˝ 26 ¼˝ 29 ¾˝
21"
48"
SBBC54*
52 ½˝ 55 ¾˝ 28 ½˝ 31 ¾˝
24"
51"
53 ¼˝ 56 ¾˝ 29 ¼˝ 32 ¾˝
24"
51"
SBBC57*
55 ½˝ 58 ¾˝ 31 ½
˝
34 ¾˝
27"
54"
56 ¼˝ 59 ¾˝ 32 ¼˝ 35 ¾˝
27"
54"
SBBC60*
58 ½˝ 61 ¾˝ 34 ½
˝
37 ¾˝
30"
57"
59 ¼˝ 62 ¾˝ 35 ¼˝ 38 ¾˝
30"
57"
SBBC63*
61 ½˝ 64 ¾˝ 37 ½
˝
40 ¾˝
33"
60"
62 ¼˝ 65 ¾˝ 38 ¼˝ 41 ¾˝
33"
60"
★
Dimensions “A” and “B” minimum requirements include optional decorative hardware clearance. You may deduct 1 1/4˝ if hardware is not used.
Cabinets will have BUTT doors
*
½˝ Overlay
Full Overlay
Cabinet
Sink
Width
16⅞”
19⅞”
22⅞”
25⅞”
28⅞”
(if centered
with doors)
Sink Base Blind Corner
