E18
Base Appliance Cabinets
Base Cabinets
Range Base
One Drawer Front
Specify R or L
RB18 R or L
RB21 R or L
RB24 R or L
RB24 BUTT
RB27 (Butt)
RB30
RB30 BUTT
RB33
RB33 BUTT
RB36
RB36 BUTT
Two Drawer Fronts
Specify R or L
u
RB39
u
RB42
u
RB45
u
RB48
u
RB48 BUTT
• One adjustable shelf
• False drawer front(s)
I
Operational End (OE) is
not
available with
Reduced Depth (RD) options
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
OE
l
RD
IF
l
TWR
l
WR
l
XS
l
GD
l
RTK
l
VTK
RB48BUTT
24˝
34 ½˝
RB39-48
24˝
34 ½˝
RB24BUTT-36BUTT
24˝
34 ½˝
RB18-24
24˝
34 ½˝
u
Deluxe Dovetailed full-width Trays (DXFWT)
not
available
Range Base 27” Deep
One Drawer Front
Specify R or L
RB1827 R or L
RB2127 R or L
RB2427 R or L
RB2427 BUTT
RB2727 (Butt)
RB3027
RB3027 BUTT
RB3327
RB3327 BUTT
RB3627
RB3627 BUTT
Two Drawer Fronts
Specify R or L
RB3927
RB4227
RB4527
RB4827
RB4827 BUTT
• One adjustable shelf
• False drawer front(s)
• Roll-out Trays (ROT) are
not
available
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
l
OE
l
RD
IF
l
TWR
l
WR
l
XS
l
GD
l
RTK
l
VTK
RB48BUTT
27˝
34 ½˝
RB39-48
27˝
34 ½˝
RB24-36BUTT
27˝
34 ½˝
RB18-24
27˝
34 ½˝
Deep Range Base
DRB30
DRB36
DRB39
DRB42
• Maximum cutout height is 6 1/2”
• Accommodates cook tops, with or without
front mounted controls
•
Note:
Be sure to follow manufacturer’s
specifications to ensure proper cooktop fit
l
PE
l
APC
l
APFC
l
FPEB
MI
l
DE
OE
RD
IF
TWR
l
WR
l
XS
GD
l
RTK
l
VTK
8˝
34 ½˝
24˝
6 ½˝
max
cutout
Down Draft Base
One Drawer Front
DDB30
DDB30 BUTT
DDB33
DDB33 BUTT
DDB36
DDB36 BUTT
DDB39
Two Drawer Fronts
DDB42
DDB45
DDB48
s
DDB48 BUTT
• Factory installed Roll-out Trays (ROT) are
not
available
• Top drawer will have scooped drawer option
(STDW), 2 1/4˝ high, 11 13/16˝ deep drawer
box
•
Not
available with any installed drawer box
accessories
•
Not
available with Full-Height Door (FHK)
option
•
Note:
Designed to be used with rear vent
systems.
Not
designed for center vent
systems
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
OE
RD
IF
TWR
l
WR
l
XS
GD
l
RTK
l
VTK
34
1
/
2
˝
24˝
13
3
/
4
˝
24˝
8
1
/
4
˝
s
Two pair of butt doors
