E23
Base Corner Cabinets
Base Cabinets
Base Corner
Cabinets
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
PE
Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI
Matching Interior
DE Integrated Decorative End
RD Reduced Depth
TWR Top Wide Rail
WR Wide Bottom Rail
XS
Extended Stile
GD Glass Doors
RTK Recessed Toe Kick
RTKP Recessed Toe Kick Peninsula
VTK Void Toe Kick
Material dimensions may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
PBBC
36
code
width
Base Blind Corner Cabinet Information
• All Base Blind Corner (BBC) cabinets
must
be pulled. Consult chart or pull dimensions and minimum wall
space requirements
• R or L indicates blind
• Door hinged on same side as blind on single door cabinets
• A 3” Base Filler (BF) is included with each Base Blind Corner (BBC) cabinet ordered, shipped separately. Base
cabinet adjacent to BBC may be ordered with an extended stile in lieu of installing supplied filler
• Base Blind Corner Universal (BBCU) cabinets are shipped blind right standard, and may be reversed in field
• Two 3” Base Fillers (BF) are included with each Peninsula Base Blind Corner (PBBC) ordered except the PBBC
27
• Optional Panel for Base Blind Corner Overlay (OPWBC) is recommended for full overlay door styles; see Base
Accessories section of this book
•
Note:
For Sink Base Blind Corner (SBBC) cabinet, see Base Cabinets section
A
B
C
Blind Right Shown
Base Blind Cabinet
Peninsula Base Blind Corner Cabinet
Base Blind Cabinet Universal
Optional
Blin
d
Corner
Overlay
3” Filler
BBC39-63
Base
Cabinet
3” Fille
r
B
A
C
Optional
Blin
d
Corner
Ov
erlay
PBBC36-48
Base
Cabinet
B
A
C
Optional
Blin
d
Corner
Ov
erlay
BBCU 36
Base
Cabinet
3” Fille
r
B
A
C
★
Dimensions “A” and “B” minimum requirements include optional decorative hardware clearance. You may deduct 1 1/4˝ if hardware is not used.
Cabinets will have BUTT doors
Wall Space “A
”
Exposed
Front “B”
Door
Open
“C”
Wall Space “A
”
Exposed
Front “B”
Door
Open
“C”
Min
★
Max.
Min
★
Ma
x
Cab.
Width Min
★
Max Min
★
Max
Cab.
Width
½˝ Overlay
Full Overlay
BBCU 36
36˝
40˝
12˝
16˝
6˝
24˝
36˝
40˝
12˝
16˝
6˝
24˝
PBBC 36 34 ½˝ 37 ¾˝ 10 ½˝ 13 ¾˝
6˝
33˝ 35 ¼˝ 38 ¾˝ 11 ¼˝ 14 ¾˝
6˝
33˝
BBC 39
37 ½˝ 40 ¾˝ 13 ½˝ 16 ¾˝
9˝
36˝ 38 ¼˝ 41 ¾˝ 14 ¼˝ 17 ¾˝
9˝
36˝
P/BBC 42 40 ½˝ 43 ¾˝ 16 ½˝ 19 ¾˝ 12˝
39˝ 41 ¼˝ 44 ¾˝ 17 ¼˝ 20 ¾˝
12˝
39˝
BBC 45
43 ½˝ 46 ¾˝ 19 ½˝ 22 ¾˝ 15˝
42˝ 44 ¼˝ 47 ¾˝ 20 ¼˝ 23 ¾˝
15˝
42˝
P/BBC 48 46 ½˝ 49 ¾˝ 22 ½˝ 25 ¾˝ 18˝
45˝ 47 ¼˝ 50 ¾˝ 23 ¼˝ 26 ¾˝
18˝
45˝
BBC 51
49 ½˝ 52 ¾˝ 25 ½˝ 28 ¾˝
21"
48"
50 ¼˝ 53 ¾˝ 26 ¼˝ 29 ¾˝
21"
48"
BBC 54*
52 ½˝ 55 ¾˝ 28 ½˝ 31 ¾˝
24"
51"
53 ¼˝ 56 ¾˝ 29 ¼˝ 32 ¾˝
24"
51"
BBC 57*
55 ½˝ 58 ¾˝ 31 ½˝ 34 ¾˝
27"
54"
56 ¼˝ 59 ¾˝ 32 ¼˝ 35 ¾˝
27"
54"
BBC 60*
58 ½˝ 61 ¾˝ 34 ½
˝
37 ¾˝ 30˝
57"
59 ¼˝ 62 ¾˝ 35 ¼˝ 38 ¾˝
30"
57"
BBC 63*
61 ½˝ 64 ¾˝ 37 ½
˝
40 ¾˝
33"
60"
62 ¼˝ 65 ¾˝ 38 ¼˝ 41 ¾˝
33"
60"
