242 / 601
E19
Base Appliance Cabinets
Base Cabinets
Drop-in Range Panel
DIP30
• Matching front panel may be trimmed to fit
drop-in range
• Toe kick included
PE
APC
APFC
FPEB
MI
DE
OE
RD
IF
TWR
WR
XS
GD
RTK
VTK
4
1
/
2
˝
8˝
DIP30
Base Microwave Cabinet 34 1/2” H w/Deep Bottom Drawer
Opening: Width: 21”; Height: 16”
BMC242434
Opening: Width: 24”; Height: 16”
BMC272434
Opening: Width: 27”; Height: 16”
BMC302434
• Deep bottom drawer
• Designed for countertop style microwaves
When ordering an unfinished
cabinet that has standard Matching
Interior (MIV), you
must
use MIP,
MIFP or FPEB to get a wood veneer matching
interior. If the cabinet is Wood Veneer
standard, ordered as All Plywood (APC) or
with Furniture Plywood Ends (FPEB, APFC),
wood veneer matching interior will be
standard.
l
PE
l
APC
l
APFC
l
FPEB
v
MI
DE
OE
l
RD
IF
TWR
l
WR
l
XS
GD
l
RTK
l
VTK
34
1
/
2
˝
24˝
Base Microwave Cabinet 34 1/2” H w/Bottom Drawer–Extended Opening
Opening: Width: 24”; Height: 19”
BMCE272434
Opening: Width: 27”; Height: 19”
BMCE302434
• 4” high drawer box
• Designed for countertop style microwaves
When ordering an unfinished
cabinet that has standard Matching
Interior (MIV), you
must
use MIP,
MIFP or FPEB to get a wood veneer matching
interior. If the cabinet is Wood Veneer
standard, ordered as All Plywood (APC) or
with Furniture Plywood Ends (FPEB, APFC),
wood veneer matching interior will be
standard.
l
PE
l
APC
l
APFC
l
FPEB
v
MI
DE
OE
l
RD
IF
TWR
l
WR
l
XS
GD
l
RTK
l
VTK
34
1
/
2
˝
24˝
Base Microwave Cabinet 46 1/2” H
Opening: Width 21”; Height 16”
BMC242446
Opening: Width 24”; Height 16”
BMC272446
Opening: Width 27”; Height 16”
BMC302446
• One adjustable shelf
• Standard cabinet ceiling construction,
finished top required
• Designed for countertop style microwaves
• Use Microwave Kit – Compact (CMCK) to
reduce opening height to 13”
l
PE
l
APC
l
APFC
l
FPEB
v
MI
DE
OE
l
RD
IF
TWR
l
WR
l
XS
l
GD
l
RTK
l
VTK
46
1
/
2
˝
24˝
