232 / 601
E9
Base Cabinets
Base Cabinets
Base Pots and Pans Storage Four Drawer
BPPS30 •4
BPPS36 •4
• Two standard drawers
• Two deep drawers
• Prep for Warming Drawer
(PWD) option is available. See
Construction Options section in
this book
l
PE
l
APC
l
APFC
l
FPEB
MI
l
DE
OE
l
RD
IF
TWR
l
WR
l
XS
XSG
GD
l
RTK
l
RTKP
l
VTK
24˝
34
1
/
2
˝
Base Pots and Pans Storage–Clipped and Fluted Clipped Corners
Clipped Corners
i
BPPSCC3027
BPPSCC3327
BPPSCC3627
Fluted Clipped Corners
is
BPPSFCC3027
s
BPPSFCC3327
s
BPPSFCC3627
• One standard drawer
• Two deep drawers
• Prep for Warming Drawer
(PWD) option is available. See
Construction Options section in
this book
• Angled stiles extend 3˝ each side
• Nominal width is overall cabinet width. Order
Example: BPPSCC3027 is 30˝ wide
• Drawer boxes are the same as those for 24˝
deep cabinets
I
Minimum Reduced Depth (RD) is 15˝
l
PE
l
APC
l
APFC
l
FPEB
MI
DE
OE
I
RD
IF
l
TWR
WR
XS
XSG
GD
RTK
RTKP
l
VTK
24˝
34
1
/
2
˝
27˝
BPPSCC
BPPSFCC
24˝
34
1
/
2
˝
27˝
i
Deep drawer(s) will accept optional Bread
Box (BB) or Bread Box Kit (BBK)
s
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
Base Multi-Storage Drawer
BMSD24 •2
BMSD30 •2
BMSD36 •2
• Two 11˝ deep plywood drawers
• Sliding drawers will have wide
scoop to coincide with Deluxe
Roll-out Tray
• Uses Whisper Touch™ Drawer
Runners – Two Drawer Cabinets
• Optional Stainless Cutlery Divider
(SCDK) will fit into sliding drawer
• Optional Cutlery Divider (CD) can be
trimmed and field installed into top drawer
• Plate Caddy (PTC) and Adjustable Drawer
Dividers (ADD) will
not
fit into bottom
portion of both drawers
• No factory installed accessories available
• Solid wood drawers
not
available
l
PE
l
APC
l
APFC
l
FPEB
MI
DE
OE
RD
IF
TWR
l
WR
l
XS
XSG
GD
l
RTK
l
RTKP
l
VTK
34 ½˝
24˝
Base Deep Drawer Combination
BDDC18 •2•TT
BDDC24 •2•TT
BDDC30 •2•TT
BDDC36 •2•TT
• One 7˝ deep plywood drawer
• One 11˝ deep plywood drawer
• One standard Roll-out Tray (ROT)
above top drawer
• Uses Whisper Touch™ Drawer
Runners – Two Drawer Cabinets
• Solid wood drawers
not
available
• Adjustable Drawer Dividers (ADD)
not
available in top drawer
I
Minimum Reduced Depth (RD) is 21˝
l
PE
l
APC
l
APFC
l
FPEB
MI
l
DE
OE
I
RD
IF
TWR
l
WR
l
XS
XSG
GD
l
RTK
l
RTKP
l
VTK
24˝
34
1
/
2
˝
