209 / 601
D50
Wall Specialty Cabinets
Wall Cabinets
Wall Lateral Bi-Fold Cabinet
Two shelves
30” High
WLBF2430
WLBF3030
WLBF3630
Three shelves
36” High
WLBF2436
WLBF3036
WLBF3636
With Auto-open Kit
Two shelves
30” High
WLBF2430 •AO
WLBF3030 •AO
WLBF3630 •AO
Three shelves
36” High
WLBF2436 •AO
WLBF3036 •AO
WLBF3636 •AO
• Adjustable shelves
• Adjustable Soft-Close lift mechanism
standard
• With the Auto-open Kit (AO), pressing lower
corners of cabinet door triggers auto-open.
Pressing a button on activator switch triggers
auto-close. Doors can be operated manually
if desired. Multiple units can also be synced
to open and close simultaneously with the
push of one button
• Breakaway hinge engages or separates, when
an object is caught between the doors as they are closing
• Door-to-door hinge will show slightly when glass doors are
applied
• Available in full overlay door styles only
• Allow 8 11/16˝ above the cabinet for proper door
clearance
• Auto-open kit requires 110V power source at back of
cabinet
• Permaset bumpers are
not
included on doors ordered
with the Auto-open Kit (AO)
I
Not
available with Mullion glass doors (GD) option
I
Not
available with Camed glass door (GD) option
I
Prep for Glass (DRS•PREP)
not
available
I
Not
available with Crossroads (CRO), Modern Textured
(MRT) and Moire (MOI) Glass Inserts
I
Antiquity Glass Insert (ATQ)
not
available on 36˝ wide
cabinet.
•
Note
: Auto-open Kit (AO) requires field installation
•
Note:
Square doors will be supplied when ordered in
arched door styles
Any wall cabinet over 24˝ wide or 30˝ high or
higher with a depth greater than 12˝ and/or
with butt doors
must
be installed between two
(2) cabinets, a cabinet and a wall or supported from below
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
RD
l
ID
TWR
XS
I
GD
•AO
14 1/ ˝
17 / ˝
7 / ˝
8 / ˝
30˝
36˝
12˝
30˝
36˝
12˝
Wall Pantry Pull-out
30” High
i
WPP930
WPP1230
33” High
i
WPP933
WPP1233
36” High
i
WPP936
WPP1236
39” High
i
WPP939
WPP1239
42” High
;i
WPP942
;
WPP1242
• Three adjustable shelves
• Shelves have solid wood floor with chrome
wire side rails
• Shelves are 9 1/2˝ deep
• Shelf widths are 4 1/4˝ or 7 1/8˝
• Unit slides on full extension side-mount
runners
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
RD
ID
TWR
l
XS
GD
39˝
42˝
12˝
12˝
30˝
12˝
33˝
12˝
36˝
12˝
i
Doors are square except full overlay arch door
styles. Laminate door styles will always be
square. Huntley, Scarbourough and Veranda
doors will have a solid, recessed flat panel.
;
One adjustable shelf above pull-out
Wall Pantry Pull-out Stack
Specify R or L
48” High
i;
WPPST948 R or L
WPPST1248 R or L
51” High
i;
WPPST951 R or L
WPPST1251 R or L
54” High
i;
WPPST954 R or L
WPPST1254 R or L
• Two vertical compartments with fixed rail
and floor
• Bottom door is always square
I
Glass doors available for top doors only
Any wall cabinet over 24˝ wide or
30˝ high or higher with a depth
greater than 12˝ and/or with butt
doors
must
be installed between two (2)
cabinets, a cabinet and a wall or supported
from below
l
PE
l
APC
l
APFC
l
FPEB
MI
l
DE
RD
ID
TWR
XS
I
GD
54˝
48˝
51˝
12˝
12˝
i
Doors are square except full overlay arch door
styles. Laminate door styles will always be
square. Huntley, Scarbourough and Veranda
doors will have a solid, recessed flat panel.
;
Glass door option
not
available
