212 / 601
D53
Wall Specialty Cabinets
Wall Cabinets
Organizers
O24
O27
O30
O33
O36
• 5/8” wood veneer construction
• Quartersawn door styles will be supplied in
plain sawn wood
• Painted hardwood supplied for EverCore™
• Vinyl edge banding applied to edges of
cabinet
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
•
Note:
This cabinet features “frameless” type
construction
When using an Organizer (O—)
Cabinet or Spice Drawer Cabinet
(SDC), which have flush ends standard, under a
wall cabinet at the end of a run, either attach
Furniture Ends (FE) or order a 3/16” Wood Skin (WSK) for
the wall cabinet to flush the ends. (There will be a seam.)
Also, consider ordering a furniture matching wall end
panel if the height of the finished product allows it. For an
alternative, see our Organizer Wall Cabinet in the Office
Cabinet section.
PE
APC
APFC
FPEB
v
MI
DE
RD
ID
TWR
XS
GD
6˝
6˝
6˝
5
7
/
8
˝
7
3
/
8
˝
O33-O36
5
7
/
8
˝
7
3
/
8
˝
9
3
/
4
˝
O24-27
5
3
/
4
˝ 9
3
/
4
˝
5
3
/
4
˝ 5
3
/
4
˝
9
3
/
4
˝
9
3
/
4
˝ 5
3
/
16
˝
6
11
/
16
˝
5
3
/
16
˝
6
11
/
16
˝
O30
Wall Filler Pull-out
Three adjustable shelves
30” High
WFP3•30
2 1/8” shelf width
WFP6•30
5 1/8” shelf width
33” High
WFP3•33
2 1/8” shelf width
WFP6•33
5 1/8” shelf width
Four adjustable shelves
36” High
WFP3•36
2 1/8” shelf width
WFP6•36
5 1/8” shelf width
39” High
WFP3•39
2 1/8” shelf width
WFP6•39
5 1/8” shelf width
Five adjustable shelves
42” High
WFP3•42
2 1/8” shelf width
WFP6•42
5 1/8” shelf width
• Quartersawn door styles will be supplied in
plain sawn wood
• Painted hardwood supplied for EverCore™
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Unit slides on full extension side-mount
runners
• Recommended installation is between two
cabinets
• Installation may also be made between a
cabinet and a wall or a cabinet and an end
panel with stile
• Filler is included, but unattached. Unit should be installed
before removing shipping brace and attaching filler
• A filler overlay is recommended for full overlay door styles;
must
be ordered separately
Do
not
use filler pullouts (WFP, BFP, BSPP) at
the end of cabinet runs or next to appliances.
They
must
be installed between two cabinets or
a cabinet and an end panel.
PE
APC
APFC
FPEB
MI
DE
RD
ID
TWR
XS
GD
30˝
33˝
36˝
39˝
42˝
Install decorative hardware
prior to attaching filler
to pull-out unit
Side View
Filler
Filler
11 / ˝
