208 / 601
D49
Wall Specialty Cabinets
Wall Cabinets
Tambour Storage Angle
TSA2418
I
TSA2718
• Tambour opens to allow 14” access height
• Tambour tension controlled with thumb
screw adjustment
• This unit is shipped with the sides at 90° to
the face frame
• Painted hardwood supplied for EverCore™
•
Not
available in Alder–Rustic door styles
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
•
Installation Note:
These units may be installed flush
with the face frame of a wall angle (WA) cabinet by
trimming the height
l
PE
l
APC
l
APFC
I
FPEB
l
MI
DE
RD
ID
TWR
XS
GD
18
1
/
2
˝
11
1
/
4
˝ 14
1
/
4
˝
13
1
/
2
˝
opening
I
Furniture Plywood Ends (FPEB) standard;
recommended Matching Interior option is
MIFP
Wall Tambour Cabinet
No shelf
12” Deep
36” High
WT181236 R or L
WT241236 BUTT
WT271236 (Butt)
WT301236
WT361236
One shelf
42” High
WT181242 R or L
WT241242 R or L
WT241242 BUTT
WT271242 (Butt)
WT301242
WT361242
Two shelves
48” High
WT181248 R or L
WT241248 R or L
WT241248 BUTT
WT271248 (Butt)
WT301248
WT361248
No shelf
18” Deep
36” High
WT181836 R or L
WT241836 BUTT
WT271836 (Butt)
WT301836
WT361836
One shelf
42” High
WT181842 R or L
WT241842 R or L
WT241842 BUTT
WT271842 (Butt)
WT301842
WT361842
Two shelves
48” High
WT181848 R or L
WT241848 R or L
WT241848 BUTT
WT271848 (Butt)
WT301848
WT361848
• Specify R or L for single door hinging
• Adjustable shelves
• Tambour opens to allow 15˝ access height
• Tambour tension controlled with thumb
screw adjustment
• 36” high has no shelves, 42” has one shelf and
48” has two shelves
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
ID
TWR
l
XS
l
GD
WT30-36
18˝
24˝
30˝
36˝
42˝
48˝
18˝
12˝, 18˝
WT24BUTT-27
18˝
24˝
30˝
36˝
42˝
48˝
18˝
12˝, 18˝
WT18-24
18˝
24˝
30˝
36˝
42˝
48˝
18˝
12˝, 18˝
