207 / 601
D48
Wall Specialty Cabinets
Wall Cabinets
Door Storage Angle
Specify R or L
DOSA2418 R or L
Ii
DOSA2718 R or L
• Access height is 15˝
•
Not
trimmable
•
Note:
Square doors will be supplied when
ordered in arched door styles
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
I
FPEB
l
MI
DE
RD
ID
TWR
XS
l
GD
13
1
/
2
˝
opening
12˝, 15˝
18˝
24˝, 27˝
24˝, 27˝
I
Furniture Plywood Ends (FPEB) standard;
recommended Matching Interior option is
MIFP
i
Flush Finished Ends standard
Drawer Storage Cabinet
DS15
DS18
DS21
DS24
DS27
DS30
• Three drawers with full extension side-mount
runners
• Top drawer will be slab, including DRPD,
except Somersworth and Thornton-Full door
styles which will be five-piece
• If DRPD option is selected, the bottom two
drawer fronts will be five-piece recessed
panel for Bradenton and Bradenton
Cathedral
l
PE
l
APC
l
APFC
l
FPEB
MI
l
DE
RD
ID
TWR
l
XS
GD
18˝
12˝
Drawer Storage Angle
DSA2418
I
DSA2718
• Three drawers with full extension side-mount
runners
• Top drawer will be slab, including DRPD,
except Somersworth and Thornton-Full door
styles which will be five-piece
• If DRPD option is selected, the bottom two
drawer fronts will be five-piece recessed
panel for Bradenton and Bradenton
Cathedral
When including any under cabinet
storage unit, consider using a
countertop with a loose backsplash.
This will prevent having to notch the cabinet.
l
PE
l
APC
l
APFC
I
FPEB
MI
DE
RD
ID
TWR
XS
GD
18˝
11
1
/
4
˝, 14
1
/
4
˝
24˝, 27˝
24˝, 27˝
I
Furniture plywood ends (FPEB) standard
Tambour Storage 18” H
TS18
TS21
TS24
TS27
TS30
TS33
TS36
• Tambour opens to allow 13 1/2” access
height
• Tambour tension controlled with thumb
screw adjustment
• Painted hardwood supplied for EverCore™
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
l
ID
TWR
l
XS
GD
18˝
12˝
