204 / 601
D45
Wall Hoods
Wall Cabinets
Wall Hood Design Idea 1
1. Wall Cabinets
2. Wall Cabinets (Increased Depth to 21˝; with Furniture Plywood Ends)
3. Wall Top Hinge Cabinets
4. Wall Pantry Pull-out (with Furniture Plywood Ends)
5. Base Cabinets
6. Base Cabinet (pulled to 27˝; with Furniture Plywood Ends; Void Toe Kick)
7. Base Pots and Pans Storage (pulled to 27˝; Scoop Top Drawer; Void Toe Kick)
8. Aluminum Round Legs
9. Wood Tall End Panel (cut to build box)
10. Large Cove Molding
11. Large Cove Casing
12. Solid Stock
13. Valance–Cove
14. Furniture Shelves
15. Narrow Batten Molding (applied to exposed edges)
16. Cove Light Rail
17. Toe Kick Material
18. Wall Filler
19. Wall Filler Overlay
1
3
2
16
18
19
16 4
1
9
10
13
14
15
10
11
12
2
7
6
5
17
5
8
Large Cove
Casing
Solid Stock
Large Cove
Molding
Tall End
Panel
Door Furniture
Shelf
Narrow Batten
Molding
Large Cove
Casing
Solid
Stock
Large Cove
Molding
Tall End
Panel
Door
Wall Hood Design Idea 2
1. Wall Cabinets (with Glass Inserts)
2. Wall Cabinets (Increased Depth to 15˝; with Furniture Plywood Ends)
3. Wall Hood Mantle Matching
4. Base Cabinets
5. Base Pots and Pans Storage
6. Base Microwave Cabinet
7. Deep Range Base (pulled to 27˝; with Furniture Plywood Ends)
8. Wall Column
9. Base Column
10. Classic Leg
11. Replacement Drawer Front
12. Ogee Edging
13. Small Cove Light Rail
14. Small Cove Molding
15. Large Starter Molding
16. Cove Corbel
17. Toe Kick Material
1
3
2
8
8
4
12
13
16
14
15
12
4 5
9
11
9 6
7
1
10
10
17
SmallCove
Molding
Large
Starter
Molding
13
Wall Hood Design Idea 3
1. Wall Cabinets (with Integrated Extended Stile
2. Wall Hood Mantle Matching
3. Base Cabinets
4. Base Cabinets (pulled to 27˝; with Furniture Plywood Ends)
5. Range Base 27˝ D
6. Roman Spindle with filler behind
7. Tall Column
8. Large Cove Molding
9. Large Starter Molding
10. Small Cove Molding
11. Solid Stock
12. Woven Corbel
13. Small Cove Light Rail
14. Ogee Edging
15. Toe Kick Material
1
1
7
8
9
10
11
12
13
14
14
13
15
7
2
3 6
6
5
4
3
Large Cove
Molding
Small
Cove
Molding
Woven
Corbel
Solid Stock
Large
Starter
Molding
