Wall Corner Cabinets
Wall Cabinets
Wall Angle Wood Lazy Susan
Specify R or L
Two shelves
WA2430 R or L•WLS
WA2433 R or L•WLS
Three shelves
WA2436 R or L•WLS
WA2439 R or L•WLS
WA2442 R or L•WLS
• 19 1/2” diameter rotating shelves
• Rotating shelves have plywood floor and
solid wood trim
• Shelves rotate independently
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
RD
ID
TWR
XS
XSG
l
GD
13
1
/
2
˝
24˝
30˝
33˝
36˝
39˝
42˝
12˝
24˝
opening
12˝
12˝
25 ½˝
24˝
24˝
17˝
Wall Angle Double Panel 54˝ H
Specify R or L
WADP2454 R or L
• Four adjustable shelves
• Shelves shipped separately
• Available in full overlay door styles only
•
Not
available in slab door styles
•
Not
available in mitered door styles
•
Not
available in Woodgrain Laminate door
styles
I
Glass doors available for top section only
I
A solid raised center panel machined to
match the veneer raised center panel will be
supplied when glass doors are selected on
full overlay veneer raised panel door styles.
I
Not
available with Mullion glass doors (GD)
option
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
l
OE
RD
ID
TWR
XS
XSG
I
GD
54˝
12˝
12˝
12˝
25 ½˝
24˝
24˝
17˝
Wall Angle Tambour
Specify R or L
Two shelves
WAT2448 R or L
I
WAT2748 R or L
• Two adjustable shelves
• Tambour opens to allow 13 1/2” access
height
• Tambour tension controlled with thumb
screw adjustment
•
Not
available in Woodgrain Laminate door
styles
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn on pull and
tambour door
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
When including any under cabinet
storage unit, consider using a
countertop with a loose backsplash.
This will prevent having to notch the cabinet.
l
PE
l
APC
l
APFC
I
FPEB
l
MI
DE
OE
RD
ID
TWR
XS
XSG
l
GD
I
Furniture Plywood Ends (FPEB) standard;
recommended Matching Interior option is
MIFP
