174 / 601
48˝
24˝
24˝
30˝
12˝
18˝
12˝
12˝
25 ½˝
24˝
24˝
17˝
48˝
24˝
24˝
30˝
12˝
18˝
12˝
12˝
25 ½˝
24˝
24˝
17˝
48˝
51˝
54˝
30˝
33˝
36˝
18˝
12˝, 15˝
15˝
27˝
27˝
15˝
17˝
29 ¼˝
WA24
WA27
12˝
12˝
25 ½˝
24˝
24˝
17˝
D15
Wall Corner Cabinets
Wall Cabinets
Wall Angle Drawer Chrome Lazy Susan
Specify R or L
Two shelves
WAD2448 R or L•CLS
• 19 11/16” diameter rotating shelves
• Maximum weight per shelf is 18 lbs.
• Shelves rotate together
• Three drawers with full extension side-mount
runners
• Top drawer will be slab, including DRPD,
except Somersworth and Thornton-Full door
styles which will be five-piece
• If DRPD option is selected, the bottom two
drawer fronts will be five-piece recessed
panel for Bradenton and Bradenton
Cathedral
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
OE
RD
ID
TWR
XS
XSG
l
GD
New
Gray color coding indicates new product, size or code.
Wall Angle Drawer Wood Lazy Susan
Specify R or L
Two shelves
WAD2448 R or L•WLS
• 19 1/2” diameter rotating shelves
• Shelves rotate independently
• Rotating shelves have plywood floor and
solid wood trim
• Three drawers with full extension side-mount
runners
• Top drawer will be slab, including DRPD,
except Somersworth and Thornton-Full door
styles which will be five-piece
• If DRPD option is selected, the bottom two
drawer fronts will be five-piece recessed
panel for Bradenton and Bradenton Cathedral
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
OE
RD
ID
TWR
XS
XSG
l
GD
Wall Angle Stack
Specify R or L
Two shelves
48” High
WAST2448 R or L
I
WAST2748 R or L
Two shelves
51” High
WAST2451 R or L
I
WAST2751 R or L
Three shelves
54” High
WAST2454 R or L
I
WAST2754 R or L
• Two vertical compartments with fixed rail
and floor
• Bottom shelves are adjustable
• Shelves shipped separately
• Bottom door is always square
I
Glass doors available for top doors only
I
To get glass on bottom door, order
appropriate replacement door with glass
option
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
I
PE
l
APC
l
APFC
I
FPEB
l
MI
DE
l
OE
RD
ID
TWR
XS
XSG
I
GD
I
Furniture Plywood Ends (FPEB) standard;
recommended Matching Interior option is
MIFP
