D12
Wall Corner Cabinets
Wall Cabinets
Wall Angle 12˝ Deep
Specify R or L
No shelf
WA2412 R or L
WA2415 R or L
WA2418 R or L
One shelf
i
WA2424 R or L
Two shelves
WA2430 R or L
WA2433 R or L
Three shelves
WA2436 R or L
WA2439 R or L
WA2442 R or L
sI
WA2448 R or L
Four shelves
sI
WA2454 R or L
• Adjustable shelves
I
Wall Top Wide Rail (WTWR) available on
12˝–36˝ high cabinets only
I
Modern Frosted (MRT) and Moire (MOI)
Glass Inserts
not
available on 54˝ H cabinets
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
Do
not
design a corner cabinet
adjacent to an object deeper than
the end panel. The door of the
corner cabinet may
not
function properly.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
OE
RD
ID
I
TWR
XS
XSG
I
GD
13
1
/
2
˝
opening
24˝
12˝
15˝
18˝
23 ½˝
30˝
33˝
36˝
39˝
42˝
48˝
54˝
12˝
24˝
12˝
12˝
25 ½˝
24˝
24˝
17˝
i
Shelf is factory installed and
not
removable
s
Available in full overlay door styles only
I
Not
available with Mullion glass doors (GD)
option
Wall Angle 15˝ Deep
Specify R or L
No shelf
WA2712 R or L
WA2715 R or L
WA2718 R or L
One shelf
i
WA2724 R or L
Two shelves
WA2730 R or L
WA2733 R or L
Three shelves
WA2736 R or L
WA2739 R or L
WA2742 R or L
• Adjustable shelves
• Furniture Plywood Ends (FPEB) standard;
recommended Matching Interior option is
MIFP
• Flush Finished Ends standard
I
APFC standard when APC option is selected
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
Full overlay doors on cabinets with
an angled front are intentionally
narrower to allow proper clearance
of adjacent cabinets.
PE
l
APC
I
APFC
v
FPEB
l
MI
DE
l
OE
RD
ID
l
TWR
XS
XSG
l
GD
27˝
27˝
15˝
13
2
1
/ ˝
opening
12˝
15˝
18˝
23
30˝
33˝
36˝
39˝
42˝
2
1
/
˝
15˝
27˝
27˝
15˝
17˝
29 ¼˝
i
Shelf is factory installed and
not
removable
Wall Angle Chrome Lazy Susan
Specify R or L
Two shelves
WA2430 R or L•CLS
WA2433 R or L•CLS
Three shelves
WA2436 R or L•CLS
WA2439 R or L•CLS
WA2442 R or L•CLS
• 19 1/2” diameter rotating shelves
• Maximum weight per shelf is 18 lbs.
• Shelves rotate together
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
RD
ID
TWR
XS
XSG
l
GD
New
