Tall Cabinets
F3
Tall Cabinets
Utility Cabinets 60 1/2” High 24” Deep
Single Door
i
U92460 R or L
U122460 R or L
U152460 R or L
U182460 R or L
U212460 R or L
U242460 R or L
Double Door
U242460 BUTT
U272460 (Butt)
u
U302460
U302460 BUTT
u
U332460
U332460 BUTT
u
U362460
U362460 BUTT
• No shelf
• Shelf Kit (SK)
must
be ordered separately; see
Shelving section of this book
• All door styles furnished square
• No center rail for Adrian, Amberly,
Captiva, Fayetteville, Fayetteville Cathedral,
Castlewood, Edgemont, Englewood, Lennox
Court, Newburgh, Parkdale, Stanford and
Summit door styles
• Factory installed Roll-out Trays (ROT) are
not
available on Utility Cabinets wider than 24˝
Remember to attach a Mullion
Strip Utility Bottom (MSUB) to tall cabinets
30” or wider when planning to field install roll-
out trays. This will remove the center stile and replace it
with a mullion strip on the left door.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
IF
l
WR
l
XS
GD
l
RTK
l
VTK
60
1
/
2
˝
24˝
i
Huntley, Scarbourough, Veranda doors will
have a solid, recessed flat panel.
u
3” center stile
Utility Combination
84” High
i
UC242484 BUTT
UC302484
UC362484
90” High
i
UC242490 BUTT
UC302490
UC362490
96” High
i
UC242496 BUTT
UC302496
UC362496
• Four adjustable shelves and one closet rod
included
• Includes adjustable shelves in upper section:
84˝ high—one shelf; 90˝ high—two shelves;
96˝ high—three shelves
• No center rail on tall door for Adrian,
Beale, Captiva, Carter, Castlewood,
Edgemont, Edgemont Cathedral, Englewood,
Edmundton, Fayetteville, Fayetteville
Cathedral, Grange, Holace, Jackson, Jasper,
Kensie, Lennox Court, Madison, Maris,
Newburgh, Parkdale, Stanford, Summit,
Torrington and Veranda door styles
• Toe kick is shipped separately on 96˝ high
cabinets
I
WR and RTK
not
available 96” high cabinets
I
Glass doors available for top doors only
I
VTK is
not
available on 96” H cabinets
Remember to order a 3/16” skin
(WSK) for the exposed ends of 93” &
96” high cabinets to conceal the
seam between the loose toe kick and the
cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
l
RD
IF
I
WR
l
XS
I
GD
I
RTK
I
VTK
84˝
90˝
96˝
24˝
23
1
/
2
˝
30˝
36˝
i
Roll-out Trays (ROT) are
not
available
Utility Combination–Shelves Left
84” High
i
UC242484 BUTT•SL
UC302484 •SL
UC362484 •SL
90” High
i
UC242490 BUTT•SL
UC302490 •SL
UC362490 •SL
96” High
i
UC242496 BUTT•SL
UC302496 •SL
UC362496 •SL
• Four adjustable shelves and one closet rod
included
• Includes adjustable shelves in upper section:
84˝ high—one shelf; 90˝ high—two shelves;
96˝ high—three shelves
• No center rail on tall door for Adrian,
Beale, Captiva, Carter, Castlewood,
Edgemont, Edgemont Cathedral, Englewood,
Edmundton, Fayetteville, Fayetteville
Cathedral, Grange, Holace, Jackson, Jasper,
Kensie, Lennox Court, Madison, Maris,
Newburgh, Parkdale, Stanford, Summit,
Torrington and Veranda door styles
• Toe kick is shipped separately on 96˝ high
cabinets
I
WR and RTK
not
available 96” high cabinets
I
Glass doors available for top doors only
I
VTK is
not
available on 96” H cabinets
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
l
RD
IF
I
WR
l
XS
I
GD
I
RTK
I
VTK
24˝
84˝
90˝
96˝
23
1
/
2
˝
30˝
36˝
i
Roll-out Trays (ROT) are
not
available
