Base Cabinets
E74
Base Accessories
Universal Base End Panel
UBEP
• 3/4” thick frame with square recessed panel
• Reversible, may be used on either right or left
end
•
Not
available in Laminate door styles
•
Not
available in High-Gloss Laminate door
styles
•
Not
available in Sturbridge; Beale, Hayward
and Manchester supplied plain sawn
• Field installation only
I
Wide Bottom Rail—field notch for toe kick
PE
APC
APFC
FPEB
MI
RD
I
WR
RTKP
VTK
34
1
/
2
˝
3
/
16
˝
23
7
/
8
˝
¾˝
Recessed Matching Base End Panel
RMBEP •M
Peninsula
PRMBEP •M
• 3/4” thick
• Quartersawn solid wood
• Recessed panel grain runs horizontally
• Inside of matching panel bottom rail will line
up with inside bottom rail of door
• Reversible, may be used on either right or left
end
• Peninsula panel has routed door profile front
and back
• Available in Sturbridge Oak door style only
• Field installation only
I
Wide Bottom Rail—field notch for toe kick
PE
APC
APFC
FPEB
MI
RD
I
WR
RTKP
VTK
Will not fit flush against 1/2" end panel,
3/16" shim is recommended
34
1
/
2
˝
23
7
/
8
˝
Slab Matching Base End Panel
SMBEP •M
Peninsula
PSMBEP •M
• 3/4” thick
• Quartersawn solid wood
• Inside of matching panel bottom rail will line
up with inside bottom rail of door
• Reversible, may be used on either right or left
end
• Available in Sturbridge Oak door style only
• Field installation only
I
Wide Bottom Rail—field notch for toe kick
PE
APC
APFC
FPEB
MI
RD
I
WR
RTKP
VTK
Will not fit flush against 1/2” end panel,
a 3/16” shim is recommended
34
1
/
2
˝
23
7
/
8
˝
Overlay Panel For Base Blind Corner Cabinets
OPWBC30
• Available in full overlay door styles only
• Field miter
• Quartersawn Oak door styles are 3/4˝
quartersawn wood with matching door
profile on all sides. Quartersawn Cherry and
Maple door styles are quartersawn wood
veneer
• Solid wood or Laminate with door edge
profile four sides
PE
APC
APFC
FPEB
MI
RD
WR
RTKP
VTK
9˝
