Tall Cabinets
F2
Tall Cabinets
Note
: Remember to remove the white plastic “feet” from the bottom of all tall cabinets before
installation. Their sole purpose is to protect the floor after the cabinets are unboxed. Leaving them on
will result in uneven installation.
Utility Cabinets 24” Deep
Specify R or L
84” High
i;
U92484 R or L
U122484 R or L
U152484 R or L
U182484 R or L
U212484 R or L
U242484 R or L
U242484 BUTT
U272484 (Butt)
u
U302484
U302484 BUTT
u
U332484
U332484 BUTT
u
U362484
U362484 BUTT
87” High
i;
U92487 R or L
U122487 R or L
U152487 R or L
U182487 R or L
U212487 R or L
U242487 R or L
U242487 BUTT
U272487 (Butt)
u
U302487
U302487 BUTT
u
U332487
U332487 BUTT
u
U362487
U362487 BUTT
90” High
i;
U92490 R or L
U122490 R or L
U152490 R or L
U182490 R or L
U212490 R or L
U242490 R or L
U242490 BUTT
U272490 (Butt)
u
U302490
U302490 BUTT
u
U332490
U332490 BUTT
u
U362490
U362490 BUTT
93” High
i;
U92493 R or L
U122493 R or L
U152493 R or L
U182493 R or L
U212493 R or L
U242493 R or L
U242493 BUTT
U272493 (Butt)
u
U302493
U302493 BUTT
u
U332493
U332493 BUTT
u
U362493
U362493 BUTT
96” High
i;
U92496 R or L
U122496 R or L
U152496 R or L
U182496 R or L
U212496 R or L
U242496 R or L
U242496 BUTT
U272496 (Butt)
u
U302496
U302496 BUTT
u
U332496
U332496 BUTT
u
U362496
U362496 BUTT
• Includes adjustable shelves
in upper section: 84” & 87”
high—one shelf; 90” & 93”
high—two shelves; 96” high—
three shelves
• No center rail on tall door
for Adrian, Beale, Captiva,
Carter, Castlewood, Edgemont,
Edgemont Cathedral,
Englewood, Edmundton,
Fayetteville, Fayetteville
Cathedral, Grange, Holace,
Jackson, Jasper, Kensie, Lennox
Court, Madison, Maris,
Newburgh, Parkdale, Stanford, Summit,
Torrington and Veranda door styles
• Factory installed Roll-out Trays (ROT) are
not
available on Utility Cabinets wider
than 24˝
• Toe kick is shipped separately on 93˝ &
96˝ high cabinets
I
When Inverted Frame (IF) is chosen in
arched door styles, U18, U24, U24BUTT
and U36, cabinets will have arched doors.
All other cabinet sizes will be supplied
with square doors
I
WR and RTK
not
available on 93” & 96”
high cabinets
I
Glass doors available for top doors only
I
VTK is
not
available on 93” and 96” high
cabinets
•
Note
: Shelf Kit (SK) for lower section
must
be ordered separately; see Shelving
section of this book
Remember to order a 3/16”
skin (WSK) for the exposed
ends of 93” & 96” high cabinets
to conceal the seam between the loose
toe kick and the cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
I
IF
I
WR
l
XS
I
GD
I
RTK
I
VTK
24˝
U9-24
U24 BUTT-
U27 BUTT
24˝
84˝
87˝
90˝
93˝
96˝
84˝
87˝
90˝
93˝
96˝
23 ½˝
27˝
30˝
33˝
36˝
84˝
87˝
90˝
93˝
96˝
23 ½˝
27˝
30˝
33˝
36˝
U30-36
with 3” center stile
24˝
23 ½˝
27˝
30˝
33˝
36˝
i
Doors are square except full overlay arch door styles. Laminate door styles will always
be square. Huntley, Scarbourough and Veranda doors will have a solid, recessed flat
panel.
;
Glass door option
not
available
u
3” center stile
Gray color coding indicates new product, size or code.
Utility Cabinets 60 1/2” High 12” Deep
Single Door
i
U91260 R or L
U121260 R or L
U151260 R or L
U181260 R or L
U211260 R or L
U241260 R or L
Double Door
U241260 BUTT
U271260 (Butt)
u
U301260
U301260 BUTT
u
U331260
U331260 BUTT
u
U361260
U361260 BUTT
• No shelf
• Shelf Kit (SK)
must
be ordered
separately; see Shelving
section of this book
• All door styles furnished
square
• No center rail for Adrian,
Amberly, Captiva, Fayetteville,
Fayetteville Cathedral,
Castlewood, Edgemont,
Englewood, Lennox Court,
Newburgh, Parkdale, Stanford
and Summit door styles
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
IF
l
WR
l
XS
GD
l
RTK
l
VTK
60
1
/
2
˝
12˝
i
Huntley, Scarbourough, Veranda doors will
have a solid, recessed flat panel.
u
3” center stile
