Deep Sink Base 27˝ Deep
DSB3027 BUTT
DSB3627 BUTT
• Will
not
accommodate Roll-out Trays (ROT)
• 3˝ stiles are routed to 1 1/2˝ in the door area
• Includes a Touch-Up Kit (TUK)
•
Note
: Be sure to follow manufacturer’s
specifications to ensure proper sink fit
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
l
RD
IF
TWR
l
WR
l
XS
XSG
l
GD
l
RTK
RTKP
l
VTK
34 ½˝
5 ½˝
8¾˝
max
cutout
5˝
3˝
3˝
27˝
Apron Sink Base
APSB30
APSB33
APSB36
• No shelf
• 3” top stiles
• Maximum cutout height is 8 3/4˝
• Mullion strip attached to left door
• Additional support rails are required–refer to
sink manufacturer
• Includes a Touch-Up Kit (TUK)
•
Note
: Be sure to follow manufacturer’s
specifications to ensure proper sink fit
To avoid cutting the side walls of a
sink base cabinet, make sure your
sink base cabinet is at least 2 1/2”
wider than the overall width of your sink. If
your overall front-to-back sink depth is 22
1/2” or greater use a 27” deep sink base.
PE
l
APC
APFC
v
FPEB
l
MI
DE
l
RD
IF
TWR
l
WR
l
XS
XSG
l
GD
RTK
RTKP
l
VTK
3˝
34
29˝
24˝
4
6˝
3˝
8
max
cutout
½˝
¾˝
½˝
Apron Sink Base 27” Deep
APSB3027
APSB3327
APSB3627
• No shelf
• 3” top stiles
• Maximum cutout height is 8 3/4˝
• Mullion strip attached to left door
• Additional support rails are required–refer to
sink manufacturer
• Includes a Touch-Up Kit (TUK)
• Roll-out Trays (ROT) are
not
available
•
Note
: Be sure to follow manufacturer’s
specifications to ensure proper sink fit
We recommend using a Filler
Extension (FE) on 27” deep cabinets
if adjacent cabinetry will
not
be
pulled flush to the Sink Base Cabinetry
PE
l
APC
APFC
v
FPEB
l
MI
DE
l
RD
IF
TWR
l
WR
l
XS
XSG
l
GD
RTK
RTKP
l
VTK
½˝
½˝
¾˝
3˝
34
29˝
27˝
4
6˝
3˝
8
max
cutout
Apron Sink Base Extended
APSBE30
APSBE33
APSBE36
• No shelf
• 3” top stiles
• Maximum cutout height is 11 3/4˝
• Mullion strip attached to left door
• Additional support rails are required–refer to
sink manufacturer
• Includes a Touch-Up Kit (TUK)
•
Note
: Be sure to follow manufacturer’s
specifications to ensure proper sink fit
PE
l
APC
APFC
v
FPEB
l
MI
DE
l
RD
IF
TWR
l
WR
l
XS
XSG
l
GD
RTK
RTKP
l
VTK
24˝
34 ½˝
8˝
29˝
5 ½˝
11¾˝
max
cutout
3˝
3˝
