34 ½˝
24
˝
Top view
Base Cabinets
E24
Base Corner Cabinets
Base Blind Corner Universal
BBCU36
• Base Blind Corner Universal (BBCU) cabinets are
shipped blind right standard, and may be reversed in
field
• Blind panel (stile) is 9˝ wide
• Right blind shown
• False drawer front
• Full-height door
• Door is hinged from blind panel
• Two adjustable, full-depth shelves
• Filler included
• Overlay Panel for Base Blind Corner (OPWBC)
must
be ordered separately
• Factory installed Roll-out Trays (ROT) are
not
available
• Huntley, Scarbourough, Veranda doors will have a
solid, recessed flat panel.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
l
RD
TWR
l
WR
l
XS
GD
l
RTK
l
RTKP
l
VTK
34
1
/
2
˝
24˝
Base Blind Corner
Specify R or L
BBC39 R or L
BBC42 R or L
BBC45 R or L
BBC48 R or L
BBC51 R or L
BBC54 R or L
BBC57 R or L
BBC60 R or L
BBC63 R or L
• Blind panel (stile) is 8” wide
• Blind opening is covered with an unfinished panel
• R or L indicates blind
• Right blind shown
• Door is hinged from blind panel
• Filler included
• Overlay Panel for Base Blind Corner (OPWBC)
must
be ordered separately
• One adjustable shelf
• Factory installed Roll-out Trays (ROT) are
not
available
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
TWR
l
WR
l
XS
l
GD
l
RTK
l
RTKP
l
VTK
34 ½˝
34 ½˝
24˝
24˝
BBC39-51
BBC54-63
Base Blind Corner w/Wood Lazy Susan
Specify R or L Blind
BBC42 R or L•WLS
BBC45 R or L•WLS
BBC48 R or L•WLS
• Blind panel (stile) is 8” wide
• Blind opening is covered with an unfinished panel
• R or L indicates blind
• Right blind shown
• Door is hinged from blind panel
• Filler included
• Overlay Panel for Base Blind Corner (OPWBC)
must
be ordered separately
• Two half-circle shelves, rotate and slide out
individually
• Rotating shelves have plywood floor and solid wood
trim
• All Wood Lazy Susan also available as field installed
kit; see Base Accessories section of this book
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
RD
TWR
l
WR
l
XS
l
GD
l
RTK
l
RTKP
l
VTK
34
1
/
2
˝
24˝
Base Blind Corner w/Chrome Swing-out
Specify R or L
BBC48 R or L•CSW
• Blind panel (stile) is 8” wide
• Blind opening is covered with an unfinished panel
• R or L indicates blind
• Right blind shown
• Door is hinged from blind panel
• Filler included
• Overlay Panel for Base Blind Corner (OPWBC)
must
be ordered separately
• One standard drawer
• Two full swing shelves rotate individually
• Shelf height is adjustable
• Shelf is non-stick coated maple melamine with chrome gallery rails
•
Note
: Swing-out will
not
fully open if a wall, another cabinet,
appliance or any other obstruction deeper than 24” is next to
swing-out side end panel
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
RD
TWR
l
WR
l
XS
l
GD
l
RTK
l
RTKP
l
VTK
