Base Cabinets
E15
Base Cabinets
Apron Sink Base Extended 27” Deep
APSBE3027
APSBE3327
APSBE3627
• No shelf
• 3” top stiles
• Maximum cutout height is 11 3/4˝
• Mullion strip attached to left door
• Additional support rails are required–refer to
sink manufacturer
• Includes a Touch-Up Kit (TUK)
• Roll-out Trays (ROT) are
not
available
•
Note
: Be sure to follow manufacturer’s
specifications to ensure proper sink fit
We recommend using a Filler
Extension (FE) on 27” deep cabinets
if adjacent cabinetry will
not
be
pulled flush to the Sink Base Cabinetry
PE
l
APC
APFC
v
FPEB
l
MI
DE
l
RD
IF
TWR
l
WR
l
XS
XSG
l
GD
RTK
RTKP
l
VTK
27˝
34 ½˝
8˝
29˝
5 ½˝
11¾˝
max
cutout
3˝
3˝
Sink Base Blind Corner
Specify R or L
SBBC51 R or L
SBBC54 R or L
SBBC57 R or L
SBBC60 R or L
SBBC63 R or L
• Blind panel (stile) is 8” wide
• Blind opening is covered with an unfinished
panel
• R or L indicates blind
• Right blind shown
• Door is hinged from blind panel
• Filler included
• Overlay Panel for Base Blind Corner
(OPWBC)
must
be ordered separately
• False drawer front
• Factory installed Roll-out Trays (ROT) are
not
available
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
IF
TWR
l
WR
l
XS
XSG
l
GD
l
RTK
l
RTKP
l
VTK
24˝
34
½
˝
34
½
˝
24˝
SBBC51
SBBC54-63
Sink Base Blind Corner
Cabinet
Sink Width
SBBC51
16
⅞
”
SBBC54
19
⅞
”
SBBC57
22
⅞
”
SBBC60
25
⅞
”
SBBC63
28
⅞
”
(if centered with doors)
Sink Front
One Drawer Front
SF18 R or L
SF21 R or L
SF24 R or L
SF24 BUTT
SF27 (Butt)
SF30
SF30 BUTT
SF33
SF33 BUTT
SF36
SF36 BUTT
SF39
Two Drawer Fronts
SF42
SF45
SF48
s
SF48 BUTT
• Includes floor; shipped loose
• Optional Utensil Trays (UT and SUT) are
available
• Unit is
not
trimmable
• Includes a Touch-Up Kit (TUK)
• Use Full-Height Kitchen (FHK) option to
achieve a full-height door look
PE
l
APC
APFC
FPEB
MI
DE
RD
IF
l
TWR
l
WR
l
XS
XSG
l
GD
RTK
RTKP
VTK
SF18-24
SF42-48
SF48 BUTT
SF24 BUTT-39
34
1
/
2
˝
34
1
/
2
˝
34
1
/
2
˝
34
1
/
2
˝
s
Two pair of butt doors
