Base Cabinets
E11
Base Cabinets
Base Multi-Storage Drawer
BMSD24 •2
BMSD30 •2
BMSD36 •2
• Two 11˝ deep plywood drawers
• Sliding drawers will have wide scoop to
coincide with Deluxe Roll-out Tray
• Uses Whisper Touch™ Drawer Runners – Two
Drawer Cabinets
• Optional Stainless Cutlery Divider (SCDK)
will fit into sliding drawer
• Optional Cutlery Divider (CD) can be
trimmed and field installed into top drawer
• Plate Caddy (PTC) and Adjustable Drawer
Dividers (ADD) will
not
fit into bottom
portion of both drawers
• No factory installed accessories available
• Solid wood drawers
not
available
l
PE
l
APC
l
APFC
l
FPEB
MI
l
DE
RD
IF
TWR
l
WR
l
XS
XSG
GD
l
RTK
l
RTKP
l
VTK
34 ½˝
24˝
Base Deep Drawer Combination
BDDC18 •2•TT
BDDC24 •2•TT
BDDC30 •2•TT
BDDC36 •2•TT
• One 7˝ deep plywood drawer
• One 11˝ deep plywood drawer
• One standard Roll-out Tray (ROT) above top
drawer
• Uses Whisper Touch™ Drawer Runners – Two
Drawer Cabinets
• Solid wood drawers
not
available
• Adjustable Drawer Dividers (ADD)
not
available in top drawer
I
Minimum Reduced Depth (RD) is 21˝
l
PE
l
APC
l
APFC
l
FPEB
MI
l
DE
I
RD
IF
TWR
l
WR
l
XS
XSG
GD
l
RTK
l
RTKP
l
VTK
24˝
34
1
/
2
˝
CoreGuard® Sink Base
SB30 BUTT•CG
SB33 BUTT•CG
SB36 BUTT•CG
• Easy to clean and durable sink base helps
protect the cabinetry from everyday leaks
and spills
• Back, end and bottom panels are made of an
engineered polymer material
• Bottom panel slants 1º toward front of
cabinet and has raised ribs to slightly elevate
stored items
• Decorative end panel required for end of
peninsula or island.
Not
Included, order
separately
• No shelf
• One full-width false drawer front above
doors
• Optional Door Storage Unit (SBDSU) is
available
• Optional Utensil Trays (UT and SUT) are
available
• Will
not
accommodate Roll-out Trays (ROT)
• Includes a Touch-Up Kit (TUK)
Caution
: For an island/peninsula
installation, the CoreGuard® Sink
cabinet
must
have a minimum of
one (1) 15” cabinet or larger installed adjacent
to it in order for the island/peninsula to have
adequate structural stability. Accessories
cannot
be installed on end panels, back or
floor of the cabinet
PE
APC
APFC
FPEB
MI
DE
RD
IF
l
TWR
WR
l
XS
XSG
GD
RTK
RTKP
VTK
Opening Sizes
Cabinet
Top Width Top Depth
SB30BUTT.CG
27 ⁄
”
22 ⅜˝
SB33BUTT.CG
30 ⁄
”
22 ⅜˝
SB36BUTT.CG
33 ⁄
”
22 ⅜˝
34
1
/
2
˝
24 ˝
