Base Cabinets
E4
Base Cabinets
Base Double Door w/Two Deluxe Dovetailed Full-Width Trays
B24 BUTT•2DXFWT
B27 (Butt)•2DXFWT
s
B30 •2DXFWT
B30 BUTT•2DXFWT
s
B33 •2DXFWT
B33 BUTT•2DXFWT
s
B36 •2DXFWT
B36 BUTT•2DXFWT
• Two adjustable, full-width Roll-out Trays
(ROT)
• Roll-out Trays (ROT) are 4” deep, 3/4˝ solid
wood dovetailed sides with 3/16” plywood
bottom, notched front and full extension
runners with integrated buffer
I
Reduced Depth (RD) available in 18˝ and 21˝
depths only
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
RD
IF
l
TWR
l
WR
l
XS
XSG
l
GD
l
RTK
l
RTKP
l
VTK
24˝
34
1
/
2
˝
s
Mullion strip attached to left door
Base Double Door w/Two Trays
B30 •2T
B33 •2T
B36 •2T
B39 •2T
B42 •2T
B45 •2T
B48 •2T
• 3” center stile
• Two adjustable Roll-out Trays (ROT)
• One adjustable shelf
• Roll-out Trays (ROT)
cannot
be included
when a Reduced Depth (RD) option of less
than 18” is selected
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
IF
l
TWR
l
WR
l
XS
XSG
l
GD
l
RTK
l
RTKP
l
VTK
B30-36
B39-48
34 ½˝
24
˝
24
˝
34 ½˝
Base Double Door w/Four Trays
B30 •4T
B33 •4T
B36 •4T
B39 •4T
B42 •4T
B45 •4T
B48 •4T
• 3” center stile
• Four adjustable, standard Roll-out Trays
(ROT)
• Roll-out Trays (ROT)
cannot
be included
when a Reduced Depth (RD) option of less
than 18” is selected
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
IF
l
TWR
l
WR
l
XS
XSG
l
GD
l
RTK
l
RTKP
l
VTK
24˝
24˝
B30-36
B39-48
34 ½˝
34 ½˝
Base Single Door w/Tray Divider
Specify R or L
B9 R or L
Without Tray Divider
B9 R or L•VTD
• Full-height door
• One full-height tray divider
• Huntley, Scarbourough, Veranda doors will
have a solid, recessed flat panel.
I
Recessed Toe Kick Both Sides (RTKB)
not
available
I
Tray divider
cannot
be included when
Reduced Depth (RD) option of less than 6˝ is
selected
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
RD
IF
TWR
l
WR
l
XS
XSG
GD
I
RTK
l
RTKP
l
VTK
24˝
34
1
/
2
˝
With divider
Without divider
24˝
34
1
/
2
˝
Gray color coding indicates new product, size or code.
