Wall Cabinets
D97
Wall Accessories
Matching Wall End Panel
Specify R or L
MWEP12 R or L
MWEP15 R or L
MWEP18 R or L
MWEP24 R or L
MWEP30 R or L
MWEP33 R or L
MWEP36 R or L
MWEP39 R or L
MWEP42 R or L
s
MWEP48 R or L
s
MWEP54 R or L
Double Panel & Stack
su=
MWEPDP54 R or L
Peninsula
PMWEP12
PMWEP15
PMWEP18
PMWEP24
PMWEP30
PMWEP33
PMWEP36
PMWEP39
PMWEP42
• 3/4” thick
• Inside of matching panel bottom rail will line
up with inside bottom rail of door
• Left shown
• Field installation only
• Laminate, mitered and slab door styles
do
not
have grooves and will
not
fit flush
against 1/2” end panel. A 3/16” shim is
recommended
• Peninsula panel has routed door profile front
and back
•
Not
available in Sturbridge Oak Square
When designing with Matching End
Panels the reveal will differ from the
cabinet door height reveal. Matching
End Panels cover the entire side of the
cabinet. See drawing for exact measurements
PE
APC
APFC
FPEB
MI
RD
ID
XS
GD
11 / ˝
12˝
15˝
18˝
23 ½˝
30˝
33˝
36˝
39˝
42˝
48˝
54˝
¾˝
/ ˝
54˝
11 / ˝
MWEPDP54
s
Available in full overlay door styles only
u
Not
available in mitered door styles
=
Not
available in slab door styles
Gray color coding indicates new product, size or code.
Matching Wall End Panel–Square Edges
MWEP12 S
MWEP15 S
MWEP18 S
MWEP24 S
MWEP30 S
MWEP33 S
MWEP36 S
MWEP39 S
MWEP42 S
s
MWEP48 S
s
MWEP54 S
Double Panel & Stack
su
MWEPDP54 S
• 3/4˝ thick panel with square edge front and
back
• Inside of matching panel bottom rail will line
up with inside bottom rail of door
• Reversible, may be used on either right or left
end
• Field installation only
• No frame recess dado
•
Not
available in Laminate door styles
•
Not
available in mitered door styles
•
Not
available in Sturbridge Oak Square
PE
APC
APFC
FPEB
MI
RD
ID
XS
GD
12˝
15˝
18˝
23 ½˝
30˝
33˝
36˝
39˝
42˝
48˝
54˝ 11 / ˝
Will not fit flush against ½˝ end
panel; a ⁄
˝ shim is recommended
54˝
11 / ˝
MWEPDP54S
s
Available in full overlay door styles only
u
Not
available in slab door styles
Gray color coding indicates new product, size or code.
