Wall Cabinets
D90
Wall Accessories
Spice Rack Kit
SRK15
9 1/2” wide
SRK18
12 1/2” wide
SRK21
15 1/2” wide
• Rack is 3 1/8” deep
• Three fixed shelves, 2 1/8” deep
• Minimum cabinet height 30”
• Includes mounting hardware
• Field installation only
PE
APC
APFC
FPEB
MI
RD
ID
XS
GD
6 / ˝
9˝
8 / ˝
Reverse-A-Shelf Kit
Three Shelves
Shelf clearance top to bottom
RSK2130
6 1/16” – 7 1/16” – 6 11/16”
RSK2136
8 1/8” – 9 1/16” – 8 11/16”
Four Shelves
RSK2142
7 3/16” – 8” – 8” – 7 5/8”
• Designed for installation in 21” wide wall
cabinets
• Shelf assembly pivots 180° for full shelf access
• Vinyl laminated shelves with woodgrain
T-molding
• Includes mounting hardware
• Field installation only
PE
APC
APFC
FPEB
MI
RD
ID
XS
GD
Under Cabinet Panels
PUCP1296
UCP1296
UCPWA
• 3/8” panel with matching Viraguard sides and applied
solid wood edge molding
• Cabinet Panel Edge (CPE8) molding may be
ordered separately; see Molding section of
this book
•
Not
available in plywood
• Painted hardwood supplied for EverCore™
•
Not
available in Sturbridge. Beale, Hayward
and Manchester supplied plain sawn
We recommend using Under
Cabinet Panels (UCP) on all wall cabinet runs.
This will give the kitchen an elegant finished
look. Unless ordered with a matching wood veneer
interior option, the under side of wall cabinets are a
natural birch material.
PE
APC
APFC
FPEB
MI
RD
ID
XS
GD
3
/
8
˝ Panel
Edge Molding
UCP 1296
13
3
/
8
˝
95
3
/
8
˝
PUCP 1296
14
1
/
2
˝
95
3
/
8
˝
13
3
/
8
˝
UCPWA
24
5
/
16
˝
15
1
/
8
˝
Wall Filler
30” High
WF3•30
WF6•30
42” High
WF3•42
WF6•42
57” High
WF3•57
WF6•57
60” High
WF3•60
WF6•60
30” High
WF3X3•30
42” High
WF3X3•42
• 3/4” thick solid wood
• Finished one side only
• Quartersawn door styles will be supplied in
plain sawn wood
• Painted hardwood supplied for EverCore™
and Laminate
Remember to use fillers with full
overlay door styles, especially
square edge profiles, when cabinets
will be against a return wall, box, pilaster or column.
Use fillers on all overlays if there is case molding on a
return wall. This will ensure proper clearance for
drawers and roll-out tray access.
PE
APC
APFC
FPEB
MI
RD
ID
XS
GD
30˝
42˝
57˝
60˝
WF
WF3x3
90°
