Wall Cabinets
D18
Peninsula Wall Cabinets
Note
: Peninsula wall cabinets
must
be installed against soffit, ceiling or supported by countertop.
Peninsula Wall Single Door 23 1/2˝ H
Specify R or L - Kitchen Side Hinging
PW1224 R or L
PW1524 R or L
PW1824 R or L
PW2124 R or L
PW2424 R or L
• Right shown
• One adjustable shelf
• Frame backs are
not
finished
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
CW
l
RD
l
ID
l
CH
TWR
l
XS
XSG
l
GD
12˝
23 ½˝
Peninsula Wall Double Door 21˝, 23 1/2˝ and 27˝ H
21” High
mr
PW3021
mr
PW3321
mr
PW3621
23 1/2” High
m
PW2424 BUTT
PW2724 (Butt)
PW3024
PW3324
PW3624
I
PW3924
I
PW4224
I
PW4524
I
PW4824
27” High
mr
PW3027
mr
PW3327
mr
PW3627
• One adjustable shelf
• Frame backs are
not
finished
Any wall cabinet over 24˝
wide or 30˝ high or higher
with a depth greater than
12˝ and/or with butt doors
must
be
installed between two (2) cabinets, a
cabinet and a wall or supported
from below
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
CW
l
RD
I
ID
I
CH
TWR
l
XS
XSG
l
GD
21˝
23 ½˝
27˝
12˝
m
Change Width (CW) option
not
available
r
Change Height (CH) option
not
available
I
Not
available in Increased Depth (ID)
Peninsula Wall Single Door 30˝ and 33˝ H
Specify R or L
Kitchen Side Hinging
30” High
im;
PW930 R or L
PW1230 R or L
PW1530 R or L
PW1830 R or L
PW2130 R or L
PW2430 R or L
33” High
im;
PW933 R or L
PW1233 R or L
PW1533 R or L
PW1833 R or L
PW2133 R or L
PW2433 R or L
• Right shown
• Two adjustable shelves
• Frame backs are
not
finished
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
CW
l
RD
l
ID
l
CH
TWR
l
XS
XSG
I
GD
30˝
33˝
12˝
i
Doors are square except full overlay arch door
styles. Laminate door styles will always be square.
Harlowe, Smithton and Vanderbilt doors will have
a solid, recessed flat panel.
m
Change Width (CW) option
not
available
;
Glass door option
not
available
Gray color coding indicates new product, size or code.
Peninsula Wall Double Door 30˝ and 33˝ H
30” High
m
PW2430 BUTT
PW2730 (Butt)
PW3030
PW3330
PW3630
I
PW3930
I
PW4230
I
PW4530
I
PW4830
33” High
m
PW2433 BUTT
PW2733 (Butt)
PW3033
PW3333
PW3633
• Two adjustable shelves
• Frame backs are
not
finished
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
CW
l
RD
I
ID
l
CH
TWR
l
XS
XSG
l
GD
30˝
33˝
12˝
m
Change Width (CW) option
not
available
I
Not
available in Increased Depth (ID)
Gray color coding indicates new product, size or code.
