Wall Cabinets
D15
Wall Cabinets
Wall Double Door 48˝ and 54˝ H
Three shelves
48” High
im
W2448 BUTT
W2748 (Butt)
W3048
W3048 BUTT
W3348
W3348 BUTT
W3648
W3648 BUTT
Four shelves
54” High
im
W2454 BUTT
W2754 (Butt)
W3054
W3054 BUTT
W3354
W3354 BUTT
W3654
W3654 BUTT
• Available in full overlay door styles only
• Shelves shipped separately
•
Not
available with Mullion Strip Wall (MSW)
I
Not
available with Camed Glass doors
I
Not
available with Mullion Glass doors
I
Modern Frosted (MRT) and Moire (MOI)
Glass Inserts
not
available on 54˝ H cabinets
I
Maximum Increased Depth (ID) is 15˝
Any wall cabinet over 24˝ wide or
30˝ high or higher with a depth
greater than 12˝ and/or with butt
doors
must
be installed between two (2)
cabinets, a cabinet and a wall or supported
from below
When using 48”–54” high cabinets
or tall stacked cabinet combinations,
remember to supply the best height
Tall End Panel [TEP] for your design needs.
Both 108” and 120” panels can be field cut to
height requirements of your design
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
CW
l
RD
I
ID
l
CH
TWR
l
XS
l
XSG
I
GD
48˝
54˝
12˝
i
Doors are square except full overlay arch door
styles. Laminate door styles will always be square.
Harlowe, Smithton and Vanderbilt doors will have
a solid, recessed flat panel.
m
Change Width (CW) option
not
available
Wall Stack Cabinet 48”, 51” and 54” H
Two shelves
48” High
im;
WST948 R or L
WST1248 R or L
WST1548 R or L
WST1848 R or L
WST2148 R or L
WST2448 R or L
m
WST2448 BUTT
WST2748 (Butt)
WST3048
m
WST3048 BUTT
WST3348
WST3348 BUTT
WST3648
WST3648 BUTT
Two shelves
51” High
im;
WST951 R or L
WST1251 R or L
WST1551 R or L
WST1851 R or L
WST2151 R or L
WST2451 R or L
m
WST2451 BUTT
WST2751 (Butt)
WST3051
m
WST3051 BUTT
WST3351
WST3351 BUTT
WST3651
WST3651 BUTT
Three shelves
54” High
im;
WST954 R or L
WST1254 R or L
WST1554 R or L
WST1854 R or L
WST2154 R or L
WST2454 R or L
m
WST2454 BUTT
WST2754 (Butt)
WST3054
WST3054 BUTT
WST3354
WST3354 BUTT
WST3654
WST3654 BUTT
• Available in full overlay door styles only
• Two vertical compartments with fixed rail
and floor
• Bottom door is always square
• Shelves shipped separately
•
Not
available with Mullion Strip Wall (MSW)
I
Glass doors available for top doors only
I
To get glass on bottom door, order
appropriate replacement door with glass
option
I
Maximum Increased Depth (ID) is 15˝
Any wall cabinet over 24˝ wide or
30˝ high or higher with a depth
greater than 12˝ and/or with butt
doors
must
be installed between two (2)
cabinets, a cabinet and a wall or supported
from below
When using 48”–54” high cabinets
or tall stacked cabinet combinations,
remember to supply the best height
Tall End Panel (TEP) for your design needs.
Both 108” and 120” panels can be field cut to
height requirements of your design
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
CW
l
RD
I
ID
CH
TWR
l
XS
l
XSG
I
GD
48˝
51˝
54˝
30˝
33˝
36˝
12˝
18˝
i
Doors are square except full overlay arch door
styles. Laminate door styles will always be square.
Harlowe, Smithton and Vanderbilt doors will
have a solid, recessed flat panel.
m
Change Width (CW) option
not
available
;
Glass door option
not
available
Gray color coding indicates new product, size or code.
