Wall Cabinets
D5
Wall Cabinets
Wall Top Hinge Cabinet 15” H w/Auto-open Kit
WTHG1515 •AO
WTHG2415 •AO
WTHG3015 •AO
WTHG3615 •AO
• No shelf
• Pressing lower corners of cabinet door
triggers auto-open. Pressing a button on
activator switch triggers auto close. Doors
can be operated manually if desired
• Multiple units can be synced to open and
close simultaneously with the push of one
button
• Auto-open kit requires 110V power source,
preferably above cabinet
• Permaset bumpers are
not
included on door
I
Antiquity Glass Insert (ATQ)
not
available on
36˝ wide cabinet.
I
Prep for Glass (DRS•PREP)
not
available
I
Not
available with Crossroads (CRO), Modern
Textured (MRT) and Moire (MOI) Glass
Inserts
I
Not
available with Mullion Glass doors
I
Not
available with Camed Glass doors
• Installation instructions supplied; read
thoroughly
•
Note
: Requires field installation
•
Note
: Square doors will be supplied when
ordered in arched door styles
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
CW
RD
l
ID
CH
TWR
l
XS
XSG
I
GD
15˝
12˝
Gray color coding indicates new product, size or code.
Wall Refrigerator Top Hinge 24˝ Deep 15˝ H
WRTHG3015
WRTHG3615
• No shelf
• Adjustable Soft-Close lift mechanism
standard
I
Antiquity Glass Insert (ATQ)
not
available on
36˝ wide cabinet.
I
Not
available with Crossroads (CRO),
Modern Textured (MRT) and Moire (MOI)
Glass Inserts
I
Prep for Glass (DRS•PREP)
not
available
I
Not
available with Mullion Glass doors
I
Not
available with Camed Glass doors
I
Minimum Reduced Depth (RD) is 12˝
•
Note
: Square doors will be supplied when
ordered in arched door styles
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
CW
I
RD
ID
CH
TWR
l
XS
XSG
I
GD
24˝
15˝
