Wall Cabinets
D2
Wall Cabinets
Caution
! Installation of a wall cabinet 30˝ or wider requires additional support,
such as attachment to a soffit, or support from below.
Wall Refrigerator 24˝ Deep 12˝ H
m
WR2412 BUTT
WR2712 (Butt)
WR3012
WR3012 BUTT
WR3312
WR3312 BUTT
m
WR3412 BUTT
WR3612
WR3612 BUTT
m
WR3712 BUTT
WR3912
WR4212
m
WR4312
WR4512
WR4812
• No shelf
• Additional support required
When designing a built-in
refrigerator area, remember that
many side by side refrigerators
measure up to 36” wide. If you have the extra
space, it is recommended to use a 37” wide
Wall Refrigerator (WR) cabinet to assure
clearance for the appliance. Also, verify the
height of the appliance to make sure you are
using the correct Wall Refrigerator cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
CW
l
RD
ID
CH
l
TWR
l
XS
XSG
l
GD
24˝
24˝
12˝
WR24-43
WR45-48
12˝
m
Change Width (CW) option
not
available
Gray color coding indicates new product, size or code.
Wall Top Hinge Cabinet 12” H
WTHG1512
WTHG2412
WTHG3012
WTHG3612
• No shelf
• Adjustable Soft-Close lift mechanism
standard
I
Antiquity Glass Insert (ATQ)
not
available on
36˝ wide cabinet.
I
Not
available with Crossroads (CRO),
Modern Textured (MRT) and Moire (MOI)
Glass Inserts
I
Prep for Glass (DRS•PREP)
not
available
I
Not
available with Mullion Glass doors
I
Not
available with Camed Glass doors
•
Note
: Square doors will be supplied when
ordered in arched door styles
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
CW
RD
l
ID
CH
TWR
l
XS
XSG
I
GD
12˝
12˝
Wall Top Hinge Cabinet 12” H w/Auto-open Kit
WTHG1512 •AO
WTHG2412 •AO
WTHG3012 •AO
WTHG3612 •AO
• No shelf
• Pressing lower corners of cabinet door
triggers auto-open. Pressing a button on
activator switch triggers auto close. Doors
can be operated manually if desired
• Multiple units can be synced to open and
close simultaneously with the push of one
button
• Auto-open kit requires 110V power source,
preferably above cabinet
• Permaset bumpers are
not
included on door
I
Antiquity Glass Insert (ATQ)
not
available on
36˝ wide cabinet.
I
Not
available with Crossroads (CRO), Modern
Textured (MRT) and Moire (MOI) Glass
Inserts
I
Prep for Glass (DRS•PREP)
not
available
I
Not
available with Mullion Glass doors
I
Not
available with Camed Glass doors
• Installation instructions supplied; read
thoroughly
•
Note
: Requires field installation
•
Note
: Square doors will be supplied when
ordered in arched door styles
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
CW
RD
l
ID
CH
TWR
l
XS
XSG
I
GD
12˝
12˝
Gray color coding indicates new product, size or code.
