Wall Cabinets
D11
Wall Cabinets
Wall Refrigerator Top Hinge 24” Deep 21” & 23 1/2” H w/Auto-open Kit
21” High
WRTHG3021 •AO
WRTHG3621 •AO
23 1/2” High
WRTHG3024 •AO
WRTHG3624 •AO
• One adjustable shelf
• Pressing lower corners of cabinet door
triggers auto-open. Pressing a button on
activator switch triggers auto close. Doors
can be operated manually if desired
• Multiple units can be synced to open and
close simultaneously with the push of one
button
• Auto-open kit requires 110V power source,
preferably above cabinet
• Permaset bumpers are
not
included on door
• 30–36” wide wall cabinets have wood veneer
plywood shelves
I
Antiquity Glass Insert (ATQ)
not
available on
36˝ wide cabinet.
I
Prep for Glass (DRS•PREP)
not
available
I
Not
available with Crossroads (CRO), Modern
Textured (MRT) and Moire (MOI) Glass
Inserts
I
Not
available with Mullion Glass doors
I
Not
available with Camed Glass doors
I
Minimum Reduced Depth (RD) is 12˝
• Installation instructions supplied; read
thoroughly
•
Note
: Requires field installation
•
Note
: Square doors will be supplied when
ordered in arched door styles
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
CW
I
RD
ID
CH
TWR
l
XS
XSG
I
GD
21˝
23 ½˝
24˝
Gray color coding indicates new product, size or code.
Wall Single Door 27˝ H
W1527 R or L
W1827 R or L
W2427 R or L
• One adjustable shelf
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
CW
l
RD
l
ID
CH
TWR
l
XS
XSG
l
GD
12˝
27˝
Wall Double Door 27˝ H
W2427 BUTT
W2727 (butt)
W3027
W3027 BUTT
W3327
W3327 BUTT
W3427 BUTT
W3627
W3627 BUTT
I
W3727 BUTT
• One adjustable shelf
Any wall cabinet over 24˝ wide or
30˝ high or higher with a depth
greater than 12˝ and/or with butt
doors
must
be installed between two (2)
cabinets, a cabinet and a wall or supported
from below
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
CW
l
RD
I
ID
CH
TWR
l
XS
XSG
l
GD
27˝
12˝
I
Not
available in Increased Depth (ID)
