Wall Cabinets
D16
Wall Cabinets
Wall Double Panel 54˝ H
i;
WDP954 R or L
WDP1254 R or L
WDP1554 R or L
WDP1854 R or L
WDP2154 R or L
WDP2454 R or L
WDP2454 BUTT
WDP2754 (Butt)
WDP3054
WDP3054 BUTT
WDP3354
WDP3354 BUTT
WDP3654
WDP3654 BUTT
• Four adjustable shelves
• Available in full overlay door styles only
• Shelves shipped separately
•
Not
available in mitered door styles
•
Not
available in slab door styles
•
Not
available in High-Gloss Laminate door
styles
I
Maximum Increased Depth (ID) is 15˝
I
Glass doors available for top section only
I
A solid raised center panel machined to
match the veneer raised center panel
will be supplied when glass doors are
selected on full overlay veneer raised panel door
styles.
I
Not
available with Mullion Glass doors
Any wall cabinet over 24˝ wide or 30˝
high or higher with a depth greater than
12˝ and/or with butt doors
must
be
installed between two (2) cabinets, a cabinet and a
wall or supported from below
When using 48”–54” high cabinets or tall
stacked cabinet combinations, remember
to supply the best height Tall End Panel
[TEP] for your design needs. Both 108” and 120”
panels can be field cut to height requirements of
your design
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
CW
l
RD
I
ID
CH
TWR
l
XS
l
XSG
I
GD
54˝
12˝
i
Doors are square except full overlay arch
door styles. Laminate door styles will always
be square. Harlowe, Smithton and Vanderbilt
doors will have a solid, recessed flat panel.
;
Glass door option
not
available
Wall Cabinet w/Spice Rack
Specify R or L
W1530 R or L•SR
W1830 R or L•SR
W2130 R or L•SR
• Right shown
• Two standard depth adjustable shelves
• Spice rack is 3 1/8” deep, rack shelf is
2 1/8” deep
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
CW
l
RD
l
ID
CH
l
TWR
l
XS
XSG
GD
30˝
12˝
9˝
6 / ˝
8 / ˝
Wall Reverse-A-Shelf
Specify R or L
Three shelves
Shelf clearance top to bottom
W2130 R or L•RS
6 1/6” – 7 1/16” – 6 11/16”
W2136 R or L•RS
8 1/8” – 9 1/16” – 8 11/16”
Four shelves
W2142 R or L•RS
7 3/16” – 8” – 8” – 7 5/8”
• Right shown
• Shelf assembly pivots 180° for full shelf
access
• Vinyl laminated shelves with woodgrain
T-molding
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
•
Note
: Cabinet is
not
reversible
We recommend using Under
Cabinet Panels (UCP) on all
wall cabinet runs. This will give
the kitchen an elegant finished look. Unless ordered
with a matching wood veneer interior option, the
under side of wall cabinets are a natural birch
material.
l
PE
l
APC
l
APFC
l
FPEB
MI
l
DE
CW
RD
ID
CH
TWR
l
XS
XSG
l
GD
30˝
36˝
42˝
12˝
