Wall Cabinets
D23
Wall Corner Cabinets
Wall Blind Corner Double Panel 54˝ H
i
WBCDP2454 R or L
WBCDP2754 R or L
WBCDP3054 R or L
WBCDP3354 R or L
WBCDP3654 R or L
WBCDP3954 R or L
• Four adjustable shelves
• Shelves shipped separately
• Available in full overlay door styles only
•
Not
available in mitered door styles
•
Not
available in slab door styles
• Overlay Panel for Wall Blind Corner
Cabinet (OPWBC) is recommended
for full overlay door styles and
must
be
ordered separately; see Base Accessories
Section of this book
I
Maximum Increased Depth (ID) is 15˝
I
Glass doors available for top section
only
I
A solid raised center panel machined to
match the veneer raised center panel
will be supplied when glass doors are selected on
full overlay veneer raised panel door styles.
I
Not
available with Mullion Glass doors
Any wall cabinet over 24˝ wide or 30˝
high or higher with a depth greater than
12˝ and/or with butt doors
must
be
installed between two (2) cabinets, a cabinet and
a wall or supported from below
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
CW
l
RD
I
ID
CH
TWR
l
XS
l
XSG
I
GD
54˝
12˝
i
Doors are square except full overlay arch
door styles. Laminate door styles will always
be square. Harlowe, Smithton and Vanderbilt
doors will have a solid, recessed flat panel.
Flush Finished Blind
FFB
• Wall Blind Corner Cabinets (WBC) are
available with Flush Finished Blind.
Specify FFB.
• Flush finished panel is solid wood
• Painted hardwood supplied for
EverCore™
• Example: WBC 2430L-FFB
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
TWR
XS
XSG
GD
12˝
Peninsula Wall Blind Corner
Specify R or L for Blind
One shelf
23 1/2” High
i
PWBC2724 R or L
i
PWBC3024 R or L
PWBC3324 R or L
PWBC3624 R or L
Two shelves
30” High
Is;
PWBC2430 R or L
i
PWBC2730 R or L
i
PWBC3030 R or L
PWBC3330 R or L
PWBC3630 R or L
33” High
Is;
PWBC2433 R or L
i
PWBC3033 R or L
PWBC3633 R or L
Three shelves
36” High
Is;
PWBC2436 R or L
i
PWBC3036 R or L
PWBC3636 R or L
39” High
Is;
PWBC2439 R or L
PWBC3039 R or L
PWBC3639 R or L
42” High
Is;
PWBC2442 R or L
i
PWBC3042 R or L
PWBC3642 R or L
• R or L indicates blind
• Left shown
• Adjustable shelves
• Frame backs are
not
finished
• See Wall Blind Corner (WBC) cabinet
chart for cabinet specifications
•
Note
: Two 3˝ fillers included. Overlay
Panel for Wall Blind Corner Cabinets
(OPWBC)
must
be ordered separately;
see Wall Accessories section of this
book
We recommend using Under Cabinet
Panels (UCP) on all wall cabinet runs.
This will give the kitchen an elegant
finished look. Unless ordered with a matching
wood veneer interior option, the under side of
wall cabinets are a natural birch material.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
l
RD
l
ID
l
CH
TWR
l
XS
XSG
I
GD
23
1
/
2
˝
30˝
33˝
36˝
39˝
42˝
12˝
8˝
i
Butt doors on peninsula side
I
Single door both sides
s
Kitchen side door is square except full overlay arch
door styles. Laminate door styles are always square.
Harlowe, Smithton and Vanderbilt doors will have a
solid, recessed flat panel.
;
Glass door option
not
available
Gray color coding indicates new product, size or code.
