Dealer Spec Book - page 198

Wall Cabinets
D28 Wall Corner Cabinets
Wall Angle Drawer
Specify R or L
WAD2448 R or L
I WAD2748 R or L
• Three drawers with full extension side-mount
runners
• Top drawer will be slab, including DRPD,
except LaSalle, Lyndale and Mandolay door
styles which will be five-piece
• If DRPD option is selected, the bottom two
drawer fronts will be five-piece recessed
panel for Bridgewater and Bridgewater
Cathedral
• Note: Full overlay door styles use a 1/2”
overlay hinge
l PE
l APC
l APFC
I FPEB
l MI
DE
CW
RD
ID
l CH
TWR
XS
XSG
l GD
48˝
24˝, 27˝ 24˝, 27˝
30˝
12˝, 15˝
18˝
I Furniture Plywood Ends (FPEB) standard;
recommended Matching Interior option is
MIFP
Wall Angle Drawer Lazy Susan
Two shelves
WAD2448 R or L•LS
• 19 1/2” diameter rotating shelves
• Three drawers with full extension side-mount
runners
• Top drawer will be slab, including DRPD,
except LaSalle, Lyndale and Mandolay door
styles which will be five-piece
• If DRPD option is selected, the bottom two
drawer fronts will be five-piece recessed
panel for Bridgewater and Bridgewater
Cathedral
• Note: Full overlay door styles use a 1/2”
overlay hinge
l PE
l APC
l APFC
l FPEB
l MI
DE
CW
RD
ID
CH
TWR
XS
XSG
l GD
48˝
24˝ 24˝
30˝
12˝
18˝
Wall Angle Drawer Wood Lazy Susan
Specify R or L
Two shelves
WAD2448 R or L•WLS
• 19 1/2” diameter rotating shelves
• Shelves rotate independently
• Rotating shelves have plywood floor and
solid wood trim
• Three drawers with full extension side-mount
runners
• Top drawer will be slab, including DRPD,
except LaSalle, Lyndale and Mandolay door
styles which will be five-piece
• If DRPD option is selected, the bottom two
drawer fronts will be five-piece recessed
panel for Bridgewater and Bridgewater
Cathedral
• Note: Full overlay door styles use a 1/2”
overlay hinge
l PE
l APC
l APFC
l FPEB
l MI
DE
CW
RD
ID
CH
TWR
XS
XSG
l GD
48˝
24˝ 24˝
30˝
12˝
18˝
