Specifications and Options
C29
Top Wide Rail
TWRB
Both Sides
TWRK
Kitchen Side
TWRP
Peninsula Side
• We offer many base and vanity cabinets
with a Top Wide Rail option. Consult option
availability chart for your desired cabinet.
• No drawer or drawer front
• Quartersawn door styles have quartersawn
top wide rail, cabinet frame is plain sawn
wood
• Painted hardwood supplied for EverCore™
• When TWRP is selected, the drawer box will
be three inches shallower than the standard
drawer box. See illustration.
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
IF
l
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
* e reveal on a cabinet with TWR varies
depending on the door overlay. See chart.
8˝*
Peninsula side
Kitchen side
Overlay 1/2˝ Full
Reveal
7 ½ ˝ 6 ⅞ ˝
Wall Top Wide Rail
WTWR
• Many wall cabinets can be ordered with
a wide top rail. Consult option availability
chart for your desired cabinet.
• Wall Top Wide Rail (WTWR) available on
12˝–36˝ high cabinets only
•
Not
available on 27” high cabinets
• This option will add 6˝ to the interior and
exterior nominal height
• Quartersawn door styles have quartersawn
top wide rail, cabinet frame is plain sawn
wood
i
Top rail on 18˝ high cabinets will be 7˝, on
24˝ high cabinets 8˝, all other heights 7 1/2˝
• Change Width (CW) option
not
available
• Change Height (CH) option
not
available
• Painted hardwood supplied for EverCore™
Remember, any replacement doors,
interior accessories or options,
including shelves, are based on the
size of original cabinet,
not
the height after
WTWR is added
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
IF
l
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
7 ½˝*
* e reveal on a cabinet with WTWR varies
depending on the door overlay. See chart.
Overlay 1/2
˝
Full
18
˝
H 6 ½
˝
5 ⅞
˝
24
˝
H
7 ½
˝
6 ⅞
˝
All other walls
7
˝
6
˝
Country English Valance Options
NF
• All Country English Arch and Frieze
cabinetry, including valances, may be ordered
without frets
• Example: WOCA1830-NF
•
Not
available in Alder–Rustic door styles
• Painted hardwood supplied for EverCore™
• Change Width (CW) option
not
available
• Change Height (CH) option
not
available
•
Note
: This is a no charge construction option
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Construction Options
