Specifications and Options
C28
Construction Options
Mullion Strip Peninsula Base–Void Center Stile
MSPBK
Kitchen Side
MSPBP
Peninsula Side
MSPBB
Both Sides
• On double door cabinets (30˝or wider) the
center stile can be removed. When this is
done, a mullion strip is attached to the left
door. Example: PB30-MSPBK
• Solid wood
• Painted hardwood supplied for EverCore™
•
Not
available with butt door cabinets
•
Note
: This option applies to base peninsula
cabinets only
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Mullion Strip Utility Top–Void Center Stile
MSUT
• On double door cabinets (30” or wider) the
center stile can be removed from the upper
section of a tall cabinet. When this is done, a
mullion strip is attached to the left door.
• Solid wood
• Painted hardwood supplied for EverCore™
• If Inverted Frame (IF) option is chosen with
this option, the smaller section, now on
bottom, will have the mullion strip
•
Not
available on cabinets with standard
Mullion Strip Base (MSB). Example: Multi-
Storage Pantry (MSP), Utility Roll-out Tray
(U-ROT).
•
Not
available with butt door cabinets
• Example: U302484-MSUT
• Change Width (CW) option
not
available
• Change Height (CH) option
not
available
•
Note
: MSUB and MSUT
not
available on
same cabinet
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Mullion Strip Utility Bottom–Void Center Stile
MSUB
• On double door cabinets (30” or wider) the
center stile can be removed from the lower
section of a tall cabinet. When this is done, a
mullion strip is attached to the left door
• Solid wood
• Painted hardwood supplied for EverCore™
• If Inverted Frame (IF) option is chosen with
this option, the larger section, now on top,
will have the mullion strip
•
Not
available with butt door cabinets
• Example: U302484-MSUB
• Change Width (CW) option
not
available
• Change Height (CH) option
not
available
•
Note
: MSUB and MSUT
not
available on
same cabinet
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Mullion Strip Oven Cabinet–Void Center Stile
MSOTB
• On 33” and 39” wide single oven cabinets the
center stile can be removed from the upper
and lower sections. When this is done, a
mullion strip is attached to the left doors.
• Solid wood
•
Not
available with butt door cabinets
• Example: OC332484S-MSOTB
• Change Width (CW) option
not
available
• Change Height (CH) option
not
available
• Painted hardwood supplied for EverCore™
•
Note
: This option applies only to the OC
33_S and OC 39_S cabinets
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
