Specifications and Options
C25
Increase Depth & Change Height
Two Dimensions
ID.CH
• Many cabinets can be changed to your
desired depth and height. Consult chart
for suggested minimums that control the
functionality of cabinet
• Any wall cabinet over 24˝ wide or 30˝ high or
higher with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
• Maximum Increased Depth (ID) for
peninsula wall cabinets is 15˝
• To Change Height (CH) on wall cabinets
18 1/16” to 23 7/16” H, select a nominal
24” H cabinet (heights
cannot
be modified
on 21” H cabinets); for heights 23 9/16” to
29 15/16” H, select a nominal 30” H cabinet
(heights
cannot
be modified on 27” H
cabinets)
• 34 1/2” H Base Cabinets can be increased in
height to 42” H; height adjustments will be
made to the door section of the base cabinet,
therefore height adjustments are
not
available
for drawer stack cabinets
• For Tall 72 1/2”–83 15/16” H, select a nominal
84” H cabinet; height adjustments will be
made to the upper section of the tall cabinet
•
Note
: Maximum cabinet width for this option
is 36”
PE
APC
APFC
FPEB
MI
DE
CW
RD
l
ID
l
CH
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Change Height
Cabinet
Wall
12˝
60˝
Base
29 ⁄
˝
42˝
Tall
Vanity Base
72½˝
29 ⁄
˝
96˝
42˝
Max. Height
Min. Height
Change Width & Change Height
Two Dimensions
CW.CH
• Many cabinets can be modified to your
desired width and height. Consult option
availability chart for your desired cabinet
• Double door cabinets
cannot
be modified to
less than 24” wide; single door cabinets
must
be used for this option
• To Change Height (CH) on wall cabinets
18 1/16” to 23 7/16” H, select a nominal
24” H cabinet (heights
cannot
be modified
on 21” H cabinets); for heights 23 9/16” to
29 15/16” H, select a nominal 30” H cabinet
(heights
cannot
be modified on 27” H
cabinets)
• 34 1/2” H Base Cabinets can be increased
in height to 42” H; height adjustments will
be made to the door section of the base
cabinet, therefore height adjustments are
not
available for drawer stack cabinets
• For Tall 72 1/2”–83 15/16” H, select a nominal
84” H cabinet; height adjustments will be
made to the upper section of the tall cabinet
PE
APC
APFC
FPEB
MI
DE
l
CW
RD
ID
l
CH
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Change Height
Cabinet
Wall
12˝
60˝
Base
29 ⁄
˝
42˝
Tall
Vanity Base
72 ½˝
29 ⁄
˝
96˝
42˝
Max. Height
Min. Height
Change Width
Cabinet
Wall and Base
9˝
48˝
Tall
9˝
36˝
Vanity Base
12˝
60˝
Max. Width
Min. Width
Construction Options
