Specifications and Options
C27
Cabinet Front Only
CFO
• Front frame and appropriate doors and
drawer heads only
• Toe kick attached where applicable except
93” and 96” tall
• Extended stiles available
We recommend using this option
on cabinetry containing no factory
installed accessories, since all
cabinet components will be eliminated
except face frame, doors and drawer fonts.
For example, order EZR36L-CFO instead of
EZR36L.WSS-CFO or B18L-CFO instead of
B18L.FWT-CFO
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
B30-CFO
W3030-CFO
U302484-CFO
VSB242134-CFO
Inverted Frame
IF
• Most Base and Vanity cabinets can be
ordered with an Inverted Frame (IF). Consult
option availability chart for your desired
cabinet
• Bottom drawer box will be 2 1/4” deep
• Factory installed Roll-out Trays (ROT) are
not
available
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
l
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
B30
Standard
B30-IF
Inverted Frame
Mullion Strip Wall
MSW
• On double door cabinets (30˝–36˝wide, up
to 42˝ high) the center stile can be removed.
When this is done, a mullion strip is attached
to the left door. Example: W3030-MSW
• Solid wood
• Painted hardwood supplied for EverCore™
• Any wall cabinet over 24˝ wide or 30˝ high or
higher with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
•
Not
available on Peninsula cabinets
•
Not
available with butt door cabinets
• Change Width (CW) option
not
available
• Change Height (CH) option
not
available
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Mullion Strip Base–Void Center Stile
MSB
• On double door cabinets (30” or wider) the
center stile can be removed. When this is
done, a mullion strip is attached to the left
door. Example: B30-MSB.
• Solid wood
• Painted hardwood supplied for EverCore™
•
Not
available with butt door cabinets
• Change Width (CW) option
not
available
• Change Height (CH) option
not
available
•
Note
: This option applies to base cabinets
only
PE
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Construction Options
