Specifications and Options
C9
Construction Options
Depth Modification
Reduced Depth
RD9
RD12
RD15
RD18
RD21
Increased Depth
ID15
ID18
ID21
ID24
• Some cabinets can be
reduced or increased in depth
to fit design requirements.
See specific cabinet
information for availability
• When this option is selected,
Cabinet Front Only (CFO) is
no longer available
• Select trays are
not
available with this option.
See individual cabinets for
specific availability
• Cabinets that normally have drawers ordered
less than 18” deep will be replaced with a false
front only
• When base cabinets are reduced, shelf will
be 10 19/32” deep; shelves 39” wide and over
will have a front cleat for additional support,
except Base Combination Drawer (BCD)
cabinets
Note
: Additional support is required
for wall cabinets increased to 15”
deep or deeper
PE
APC
l
RD9
l
RD12
l
RD15
l
RD18
l
RD21
l
ID15
l
ID18
l
ID21
l
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
Cabinet Front Only
CFO
• Front frame and appropriate
doors and drawer fronts only
• Does
not
include toe kick
•
Note
:
Cannot
be combined
with any depth modifications
or tray options
We recommend
using this option on
cabinetry
containing no factory
installed accessories, since all cabinet
components will be eliminated except face
frame, doors and drawer fonts. For example,
order BCFS36L-CFO instead of LS36L-CFO
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
l
CFO
Deluxe Recessed Panel Drawer Front
DRPD
• 5-piece drawer front (DRPD)
option is only available in
Paxton and Ridley door styles;
comes standard in Bellamy
door style
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
DRPD
