Wall Cabinets
D2
Wall Cabinets
Caution
! Installation of a wall cabinet 30˝ or wider requires additional support,
such as attachment to a soffit, or support from below.
Wall Double Door 15” H
W2715 (Butt)
W3015 BUTT
W3315 BUTT
W3615 BUTT
W3915
W4215
W4515
W4815
• No shelf
• Any wall cabinet over 24˝ wide or 30˝
high with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
BIS
MD
SV
MI
l
CFO
12˝
15˝
Wall Refrigerator 24” Deep 15” H
WR3015 BUTT
WR3315 BUTT
WR3615 BUTT
WR3915
• No shelf
• Designed for use over refrigerators where
there is adequate clearance
• Additional support required
When designing a built-in
refrigerator area, remember that
many side by side refrigerators
measure up to 36” wide. If you have the
extra space, it is recommended to use at
least a 1” filler with a 36” wide Wall
Refrigerator (WR) cabinet to assure clearance
for the appliance. Also, verify the height of the
appliance to make sure you are using the
correct Wall Refrigerator cabinet.
l
PE
l
APC
RD9
ID15
ID18
ID21
ID24
BIS
MD
SV
MI
l
CFO
24˝
15˝
Wall Single Door 18” H
Specify R or L
W2418 R or L
• No shelf
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
BIS
MD
SV
MI
l
CFO
18˝
12˝
Wall Double Door 18” H
W2418 BUTT
W2718 (Butt)
n
W3018 BUTT
W3318 BUTT
n
W3618 BUTT
W3918
W4218
W4518
W4818
• No shelf
• Any wall cabinet over 24˝ wide or 30˝
high with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
I
BIS
I
MD
I
SV
I
MI
l
CFO
12˝
18˝
n
Available with glass options (BIS, DRS.PREP,
MD, MD.PREP, SV, SV.PREP)
