Wall Cabinets
D3
Wall Cabinets
Caution
! Installation of a wall cabinet 30˝ or wider requires additional support,
such as attachment to a soffit, or support from below.
Wall Refrigerator 24” Deep 18” H
• No shelf
• Designed for use over refrigerators where
there is adequate clearance
• Additional support required
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
When designing a built-in
refrigerator area, remember that
many side by side refrigerators
measure up to 36” wide. If you have the
extra space, it is recommended to use at
least a 1” filler with a 36” wide Wall
Refrigerator (WR) cabinet to assure clearance
for the appliance. Also, verify the height of the
appliance to make sure you are using the
correct Wall Refrigerator cabinet.
l
PE
l
APC
RD9
ID15
ID18
ID21
ID24
I
BIS
I
MD
I
SV
I
MI
l
CFO
24˝
18˝
Wall Single Door 23 1/2” H
Specify R or L
n
W1224 R or L
W1524 R or L
W1824 R or L
W2124 R or L
W2424 R or L
• One adjustable shelf
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
I
BIS
I
MD
I
SV
I
MI
l
CFO
12˝
23 ½˝
n
Not
available with glass options (BIS, DRS.
PREP, MD, MD.PREP, SV, SV.PREP)
Wall Double Door 20 1/2” and 23 1/2” H
No shelf
20 1/2” High
W3021 BUTT
W3321 BUTT
W3621 BUTT
W3921
W4221
One shelf
23 1/2” High
n
W2424 BUTT
W2724 (Butt)
n
W3024 BUTT
W3324 BUTT
n
W3624 BUTT
W3924
W4224
W4524
W4824
• One adjustable shelf in 23 1/2” high
cabinet
• Any wall cabinet over 24˝ wide or 30˝
high with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
I
BIS
I
MD
I
SV
I
MI
l
CFO
12˝
20 ½˝
23 ½˝
Wall Refrigerator 24” Deep 23 1/2” H
• No shelf
• Designed for use over refrigerators where
there is adequate clearance
• Additional support required
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
When designing a built-in
refrigerator area, remember that
many side by side refrigerators
measure up to 36” wide. If you have the
extra space, it is recommended to use at least
a 1” filler with a 36” wide Wall Refrigerator
(WR) cabinet to assure clearance for the
appliance. Also, verify the height of the
appliance to make sure you are using the
correct Wall Refrigerator cabinet.
l
PE
l
APC
RD9
ID15
ID18
ID21
ID24
I
BIS
I
MD
I
SV
I
MI
l
CFO
24˝
23 ½˝
n
Available with glass options (BIS, DRS.PREP,
MD, MD.PREP, SV, SV.PREP)
Gray color coding indicates
new product, size or code
Gray color coding indicates
new product, size or code
Gray color coding indicates
new product, size or code
n
WR3018 BUTT
WR3318 BUTT
n
WR3618 BUTT
WR3918
WR4218
n
Available with Glass doors (BIS, DRS.PREP,
MD, MD.PREP, SV, SV.PREP)
n
WR3624 BUTT
WR3924
WR4224
n
Available with Glass doors (BIS, DRS.PREP,
MD, MD.PREP, SV, SV.PREP)
