Specifications and Options
C13
Construction Options
4 Deep Roll-out Trays
4DROT
• Sides, front and back, are 1/2”
solid hardwood with 3-ply
5.2mm thick plywood bottom
panel
• 1 15/16” deep scalloped finger
pull cut out
• Available for most 2 door Base
and Universal cabinets with
center stile
• Natural finish
• Shelves are omitted from
cabinets when ROT options are
selected
• 3/4 extension side mount glide
• 75 lb. capacity
• Only available in 24” deep cabinets
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
l
4DROT
6DROT
2DFWROT
MI
CFO
6 Deep Roll-out Trays
6DROT
• Sides, front and back, are 1/2”
solid hardwood with 3-ply
5.2mm thick plywood bottom
panel
• 1 15/16” deep scalloped finger
pull cut out
• Available for most 3 door Base
non butt door cabinets
• Natural finish
• Shelves are omitted from
cabinets when ROT options are
selected
• 3/4 extension side mount glide
• 75 lb. capacity
• Only available in 24” deep cabinets
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
l
6DROT
2DFWROT
MI
CFO
2 Deep Full-Width Roll-out Trays
2DFWROT
• Full-width deep tray spans the
full width of cabinet
• Sides, front and back, are 1/2”
solid hardwood with 3-ply
5.2mm thick plywood bottom
panel
• 1 15/16” deep scalloped finger
pull cut out
• Available for most Base and
Universal butt door cabinets
• Natural finish
• Shelves are omitted from
cabinets when ROT options are
selected
• 3/4 extension side mount glide
• 75 lb. capacity
• Only available in 24” deep cabinets
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
l
2DFWROT
MI
CFO
